Working model | Single pulse, continuous pulse, repeated pulse, super pulse |
Output power | 1~60W(adjustable) |
Input power | 450VA |
Laser type | Sealed-off CO2 laser |
Laser mode | Lower mode |
Laser wavelength | 10.6μm |
Divergence angle | 4mrad |
Focused spot diameter | ≤0.4mm |
Tool bit focus | F=100mm(optional ) |
Pulse width | 0.02~0.99s |
Aiming beam | Red diode laser(650nm,2mW) |
Transmission system | Spring -balanced 7 joint arms |
Cooling system | Inside-circle coolant |
Controlling system | Controlled by microcomputer |
Display screen | LCD |
Working environment temperature | 5~40℃ |
Humidity | <80% |
Air pressure | 86KPa~106 KPA |
Input power | AC220V±10%,50Hz |
Preheating-time | >5min |
Electromagnet | No electromagnet interrupt |
other working environment | No obvious shaking or airflow |
Weight | 39kgs / 65kgs |
Machine size | 183(with arms)x45x40cm; 40*45*115CM without arms |
Package Size | 125×57×62cm |
