Unionwell 0.1A,5A 10A 125/250V 25T125 G605 Series Miniature Micro switch Gas Stoves limit switch type microswitches
- Category: >>>
- Supplier: Huizhou Unionwell Sensing & Control Electronics Co. Ltd.
Share on (1600644489372):
Product Overview
Description
Unionwell G605 Series Miniature Micro switch Gas Stoves
Product Description
Features
- Small Compact Size
- Global Safety Approvals
- Long Life And High Reliability
- Customized Designs For A9# Lever
- Widely Used In The Auto Control, Appliance Control, Industrial Control, Etc.
Parameters
| Rating | P1/P11/P12 | ENEC:0.1A,125/250V 48VDC 5EA |
| UL: 0.1A,125/250V 48VDC | ||
| Gold Plated Contact Optional | ||
| 05/051/052 | ENEC:5A,125/250VAC 5(3)A 125/250VAC 5A 30VDC | |
| UL: 5A, 1/8HP 125/250VAC | ||
| 10/101 | ENEC:10(2)A,125/250VAC μ 25T125 | |
| UL: 10.1A, 1/4HP 125/250VAC | ||
| Note:250gf/Only with “OF “over “250gf” | ||
| 12 | ENEC: 12(6)A,125/250VACμ 40T125 | |
| UL: 12A,125/250VAC Note:350gf/Only with 350gf OF | ||
| Operating Frequency | Electrical | 10-30 cycles/minute |
| Mechanical | 120 cycles/minute | |
| Contact Resistance(Initiative ) | 100mΩ Max | |
| Insulation Resistance (at 500VDC) | 100MΩ Min | |
| Dielectric Strength | AC 1,000V RMS(50-60HZ) | |
| Storage Temperature | -25℃~+125℃ | |
| Storage Humidity | 85% RH Max | |
| Service Life | Electrical | 10,000-50,000 /cycles(Depend on part No.) |
| Mechanical | 1,000,000/cycles | |
Certifications
Business Partners
company information
Unionwell Advantages
1. ISO9001 & IATF16949 qualified
2. Most products are produced & tested by automatics
3. Automatic machines are designed and assembled by our own team
4. Awarded as National Innovative Technology Company
5. Strong R&D team, authorized over 30 patents
Packaging & Shipping
Package List
FAQ
Q1. Are you a trading company or manufacturer?
A: Yes. We are a manufacturer specializing in switches over 30 years.
Q2. What is your MOQ?
A : Normally, MOQ=500pcs.
Q3. What’s the warranty time?
A: 1 - 2 years.
Q4. Could you offer us free samples?
A: Yes, free samples could be provided within 2-5 days.
Q5. What ‘s the lead time of mass production?
A : About 2-4 weeks.
Q6. What’s the capacity per month?
A : Over 8 million pieces per month for micro switch series.
Over 20 million pieces per month for keyboard switch series.
Q7. Where is your plant?
A: Located in Huizhou city, Guangdong province, China.
About 70 minutes by car from Shenzhen airport and about 2 hours from HK airport.
Q8 . Could you accept OEM or ODM?
A : Yes, we have a strong R&D team. We have rich experience on OEM&ODM.
