Product Overview

Description



Product Description





560G SprayboothCeiling Filter


Speciality:The series of ceiling filters are mainly used in surface spray-paint industry,Hi-tech electronics,aerospace and other military areas.Composited of imported high-performance,anti-broker synthetic fiber in gradual technology;


Type:SP-560G; JE-560G; ”AAA”3A-560G; PE-560G


Characteristic:The outlet side of the filter media is reinforced by import PE-net ,domestic glassfiber net,nylon cloth,domestic non-flammable net.


With gradual technology, the fiber density increases gradually toward pure air, high filter efficiency,extended working life.Due to complete penetration of viscosity in media, dust particles can not pass,fully filtered air evenly spreads to form a laminar flow state to achieve the best spray results. Conforming to European DIN53438-F1 and American UL900-Class2. The outlet side is printed with EN-779 standard classifications, DIN logo, the registered trademark of SHW. Dense outlet side,the surface is reinforced by covered net scrim, low initial resistance, high dust holding capacity, good fire retardant and long working life, economical and reliable, moisture resistance, up to 100% relative humidity.


Specification:



























































































Type



Filter Class



Average
Arrestance



Average
Efficiency






Nominal
Velocity(m/s)



Rated
Airflow(m3/h



Initial
Resistance(Pa)






Final
Resistance(Pa)



Continuous
Temperature(℃)



Instantaneous


Temperature(℃)



Thickness






Sizes



SP-560G



F5



96%



50%



0.25m/s



900 m3/h



25Pa



450Pa



100℃



120℃



25 mm



1.6*21M



2.0*21M



JE-560G



F5



96%



50%



0.25m/s



900 m3/h



25 Pa



450Pa



100℃



120℃



25 mm



1.6*21M



2.0*21M



3A-560G



F5



96%



50%



0.25 m/s



900 m3/h



25 Pa



450 Pa



100℃



120℃



25 mm



1.6*21M



2.0*21M



PE-560G



F5



96%



50%



0.25 m/s



900 m3/h



25 Pa



450 Pa



100℃



120℃



25 mm



1.6*21M



2.0*21M









ceiling filter SP-600G


SP-600G





Packaging & Shipping


 Packing:PE bags
Loading port:Huangpu,China





Our Services


  It's our wish to dedicate high-grade products and earnest service to your promising career





Company Information







FAQ







Q: Are your air filter cheapest in China?


A: We can not say we are the cheapest in China, but based on same quality, we have the best price.


Q: Can you give us some discount on your air filter media?


A: We are the factory, in order not to waste your time, our price is already our best price.


Q: Can you lower the price by lowering the quality?


A: Sorry but quality is our basis to keep long term cooperation with our clients, so we never lower the quality.
