KUNFINE ISDB-T9 9 inch isdb-t full seg digital tv b-cas 2*2 tuner antenna with GPS / FM transmitter

ISDB system

Input

Input Frequency:(Brazil:174~216MHz & 470~806MHz)(Japan:170MHz ~ 770MHz)

input power:-95dBM~-0dBM

input impedance:50ohm

Demodulation

modulation system:QPSK,16-QAM,64-QAM

bandwidth:6MHz

II decoding

video decoding:MPEG4,AVC/H.264

Audio decoding standard:MPEG2,AAC

Supported language

Japan/ Portuguese/ Spanish/English

LCD screen display

RGB output

analog video output(optional)

Video output port (CVBS)

output mode:Japan:NTSC;Brazil:PAL-M

output impedance:75ohm

Output level:1.0±20mVp-p(output format CVBS)

Digital video output(optional)

HDMI 1.4

Support format:

– 1920x1080p @ 60Hz

– 1920x1080i @ 30Hz

– 1280x720p @ 30Hz

– 720x480i @ 60Hz

– 720x480p @ 60Hz

audio output

1 way 2W/8Ωloudspeaker;1way arphone

USB interface

Package Updated

machine power supply interface(+5V DC),

Input power

Car battery / Car lighter

power consumption

About 3.5W

Working Temperature

-20—75℃

size

Length 143MM×wide 88M×thickness 23MM
