Cheap PVC RFID Card Making Machine for small businesses
US $630.00-$730.00
CR80 card laminating machine PVC polycarbonate card making machine ID card fusing machine
- Category: Plastic Laminating Machines >>>
- Supplier: Wuhan,Wenlin,Technology,Co.,Ltd.
Share on:
Product Overview
Description
A3+ Teslin Paper Cards Key tags Fusing Machine
Product Description
★This laminator adopts a stable and reliable linear pushing device, which lays a solid foundation for automatic feeding,
transferring and discharging materials. The national patent number is ZL201930632526.5；; ZL201930632515.7 etc.
★The functions of automatic feeding, transferring and discharging not only save labor, the most importantly, laminating operators can operate without professional technical training.
★Ten laminating daylights, production capacity is more efficient;
★Equipped with upgraded feeding and turning device, the position is more accurate and operation is more convenient. There is no restriction on the height of operators. Female workers can also operate this machine.
transferring and discharging materials. The national patent number is ZL201930632526.5；; ZL201930632515.7 etc.
★The functions of automatic feeding, transferring and discharging not only save labor, the most importantly, laminating operators can operate without professional technical training.
★Ten laminating daylights, production capacity is more efficient;
★Equipped with upgraded feeding and turning device, the position is more accurate and operation is more convenient. There is no restriction on the height of operators. Female workers can also operate this machine.
Application Range:
Application Range: It is suitable for RFID tags, IC, ID inlay, second-generation ID cards and other high-end ID cards, bank cards, bus cards, highways, social security cards and other companies and card factories that professionally make cards.
Specification
Model | WENLIN-Jinguan7500/Jinguan5200-10 automatic laminator |
Appliance materials | PVC、PC、PET、PETG（suitable for heating and pressure characteristics materials） |
Specifications | 600mm*750mm/420mm*520mm |
Suitable Layout | 6×8、2×(5×5)、2×（3×7）、2×(3×8) etc. |
Voltage | 380V 50-60HZ |
Temperature range | Temperature range |
Pressure range： | 0-16Mpa |
Power： | 68KW/48KW |
Laminating Plate： | Aluminum Alloy |
Hydraulic Cylinder： | Single |
Daylight： | 10 daylights (10 heating& 10 cooling) |
Transferring mode： | automatic |
Feeding mode： | automatic |
Discharging mode： | automatic |
5200 Dimension： | L2,414mm*W2752mm*H2065mm |
7500 Dimension： | L3,182mm*W3440mm*H2265mm |
Gross Weight： | 8000kg/6000kg |
Packing and Transportation
Factory
Why Choose Us
1.Professional manufacturer of smart card laminating & punching machine,anti-counterfeiting labels laser marking machine with 20 years experience.
2.Premium supplier verified by SGS,passed CE & ISO9001 certificates.
3.Obtained 11 national invention patents, multi patents for utility models and software copyright.
4.High quality,custumized products and better service.
5.Cooperate with customers in many countries around the world.
2.Premium supplier verified by SGS,passed CE & ISO9001 certificates.
3.Obtained 11 national invention patents, multi patents for utility models and software copyright.
4.High quality,custumized products and better service.
5.Cooperate with customers in many countries around the world.
Company Profile
Wuhan Wenlin Technology Co., Ltd. was founded in 2001, which is a smart card making equipment R & D, production and materials supply enterprise. The laminator and punching machine for IC, ID&RFID smart card are well-praised. There are more than 1000 customers in nearly more than 50 countries and regions around the world, including the world-famous card making enterprises. The machines are widely used in the production fields of Union Pay, VISA, MasterCard, second generation ID card, residence card, social security card, double interface card and IC, ID smart card and so on.
Wenlin is a high-tech and national Torch Program project enterprise identified by the Chinese government, as well as a demonstration enterprise of scientific & technological innovation and patent transformation. The trademark “WENLIN" have been evaluated as famous trademarks of Hubei province and Wuhan city for more than 10 years.
Wenlin passed CE and ISO9001 certificates, and obtained 11 national invention patents(ZL201110189116.0;ZL201110189122.6;ZL201410139338.5;ZL201410140570.0;ZL201410139337.0;ZL201410140607.X;ZL201410125696.0;ZL201410140568.3;ZL201410139336.6;ZL201511029056.0;ZL201510513046.8),multi patents for utility models(ZL2015211392374;ZL201721920832.0;ZL20192242777.7T etc)and software copyright.
Founding century name brand, Creating hundred-years-old Wenlin. To provide the best card making solution and service for all the customers is the eternal aim of Wenlin. We’d like to cooperate with agents all over the world.
Wenlin is a high-tech and national Torch Program project enterprise identified by the Chinese government, as well as a demonstration enterprise of scientific & technological innovation and patent transformation. The trademark “WENLIN" have been evaluated as famous trademarks of Hubei province and Wuhan city for more than 10 years.
Wenlin passed CE and ISO9001 certificates, and obtained 11 national invention patents(ZL201110189116.0;ZL201110189122.6;ZL201410139338.5;ZL201410140570.0;ZL201410139337.0;ZL201410140607.X;ZL201410125696.0;ZL201410140568.3;ZL201410139336.6;ZL201511029056.0;ZL201510513046.8),multi patents for utility models(ZL2015211392374;ZL201721920832.0;ZL20192242777.7T etc)and software copyright.
Founding century name brand, Creating hundred-years-old Wenlin. To provide the best card making solution and service for all the customers is the eternal aim of Wenlin. We’d like to cooperate with agents all over the world.
