PLC control 385nm/395nm uv drying machine for flexo ink curing
- Category: >>>
- Supplier: Shenzhen Height-Led Opto-Electronics Technology Co. Ltd.
Share on (1600649698448):
Product Overview
Description
Product Description
Brand | Height-LED |
Model | HTJP-II-SE35025-BL-8 |
Curing area | 350X25mm |
Wavelength | 385nm |
Optical intensity | 26W/cm2 |
Cooling method | water cooling |
Control style | PLC+HMI |
Detection function | Temperature/voltage/current detection |
Printing speed matching | Encoder speed measurement /0-5V、0-10V Optional analog speed signal acquisition |
docking signal | Relay short circuit signal |
Alarm signal | Relay short circuit signal |
Power adjustment | digital dimming(1-100%) |
Voltage | 3P AC380V(50/60HZ) |
Total power consumption | 22.4 KW |
Ambient temperature | -10℃-50℃ |
Relative humidity | 25%-80%RH |
Customized service | All parameters can be customized according to customer needs |
Company Profile
FAQ
Q1: Why choosing HTLD UV LED curing system?
A:Our team has over 10 years combined experience in UV curing systems and can meet the requirements of each client.
Q2: Can I use UV LED curing system in our production?
A:HTLD UV curing system can be used for curing UV ink, UV adhesive UV paint, UV varnish and other UV sensitive materials.
Q3: What is UV LED curing system’s major advantages than other UV curing system?
A:Extra-long life, energy saving and environment friendly.
Q4: Which wavelength do I need?
A:It depends on your UV sensitive materials.
Q5: How much the size of emitting window do I need?
A:It depends on your production.
Q6: How much the Peak Irradiance do I need?
A:It depends on your UV sensitive materials and your Production efficiency.
Q7: The common emitting window and Peak Irradiance can not meet my requirments?
A:Do not worry! Any size of emitting window and Peak Irradiance can be customized .
Q8: Where is your company located?
A: 2/F, Building B, Sanhe international science and technology Building, Lai Wu Shan New Village ,Da Lang Road,Long Hua District, ShenZhen.
A:Our team has over 10 years combined experience in UV curing systems and can meet the requirements of each client.
Q2: Can I use UV LED curing system in our production?
A:HTLD UV curing system can be used for curing UV ink, UV adhesive UV paint, UV varnish and other UV sensitive materials.
Q3: What is UV LED curing system’s major advantages than other UV curing system?
A:Extra-long life, energy saving and environment friendly.
Q4: Which wavelength do I need?
A:It depends on your UV sensitive materials.
Q5: How much the size of emitting window do I need?
A:It depends on your production.
Q6: How much the Peak Irradiance do I need?
A:It depends on your UV sensitive materials and your Production efficiency.
Q7: The common emitting window and Peak Irradiance can not meet my requirments?
A:Do not worry! Any size of emitting window and Peak Irradiance can be customized .
Q8: Where is your company located?
A: 2/F, Building B, Sanhe international science and technology Building, Lai Wu Shan New Village ,Da Lang Road,Long Hua District, ShenZhen.
