60kva three phase soundproof canopy diesel silent generator 60 kva with Cummins 4BTA3.9-G2

Share on:

Price:$5,800.00 - $6,100.00
Price in USD:Details


Product Overview



3 (1)



  Diesel generator Details

  Model  CLK-50GF


  Frequency  50Hz/60Hz
  Voltage  380/220v(voltage can be customized)
  Optional Type  Open/soundproof/trailer
  Size of Open type  1800*750*1200mm
  Weight of Open type  950kg
  With Diesel Engine
  Brand&model  with cummins 4BTA3.9-G2
  Standby Power  64kw
  Cylinders  4 in line arrangement
  Bore*Stroke  102*120mm
  Displacement  3.9L
  Lubrication Oil Capacity  11L
  Fuel Consumption at 100% Load  212g/kw.h
  Speed Governor  Electronic
  With Alternator
  Optional Brands  Stamford/Leroy Somer/Mecc Alte/Marathon
  Exciter type  Single bearing,brushless,Self-excited
  Power factor  0.8
  Voltage adjust range  ≥5%
  Insulation Grade  H
  Protection Grade  IP23
  With Controller
  Optional brands  Deepsea/ComAp/Smartgen



  Standard equipment
    · Diesel engine  · 50℃ water cooled radiator
    · Alternator  · Silencer and flexible exhaust hose
    · Starting batteries and battery connect wires  · Digital control panel
    · Output circuit breaker  · Steel base frame
  Optional equipment
    · Sound proof  · Water heater
    · Automatic parallel synchronizing control system  · ATS
    · 50℃ water cooled radiator
