Best Quality SMD Aluminum Frame PCB Stencil for led light Manufacturer With Provided Gerber Files BOM
- Category: >>>
- Supplier: Topfast(Guangdong)Technology,Co.,Ltd.
Share on:
Product Overview
Description
TECHNICAL CAPACITY
PCB capability | ||||||
Item | PCB capability | PCB capability | PCB capability | |||
Max Layer | 60L | 8L | 36L | |||
Inner Layer Min Trace/Space | 3/3mil | 3/3mil | 3/3mil | |||
Out Layer Min Trace/Space | 3/3mll | 3.5/4mll | 3.5/4mll | |||
Inner Layer Max Copper | 6oz | 2oz | 6oz | |||
Out Layer Max Copper | 6oz | 2oz | 3oz | |||
Min Mechanical Driling | 0.15mm | 0.1mm | 0.15mm | |||
Min Laser Drilling | 0.1mm | 0.1mm | 0.1mm | |||
Max Aspect Ratio(Mechanical Driling) | 20:01 | 10:01 | 12:01 | |||
Max Aspect Ratio(Laser Drilling) | 1:01 | / | 1:01 | |||
Press Fit Hole Ttolerance | ±0.05mm | ±0.05mm | ±0.05mm | |||
PTH Tolerance | ±0.075mm | ±0.075mm | ±0.075mm | |||
NPTH Tolerance | ±0.05mm | ±0.05mm | ±0.05mm | |||
Countersink Tolerance | ±0.15mm | ±0.15mm | ±0.15mm | |||
Board Thickness | 0.4-8mm | 0.1-0.5mm | 0.4-3mm | |||
Board Thickness Tolerance(<1.0mm) | ±0.1mm | ±0.05mm | ±0.1mm | |||
Board Thickness Tolerance(≥1.0mm) | ±10% | / | ±10% | |||
Min Board Size | 10*10mm | 5*10 mm | 10*10mm | |||
Max Board Slze | 22.5*30 inch | 9*14 inch | 22.5*30 inch | |||
Contour Tolerance | ±0.1mm | ±0.05mm | ±0.1mm | |||
Min BGA | 7mil | 7mil | 7mil | |||
Min SMT | 7*10mil | 7*10mll | 7*10mll | |||
Min Solder Mask Clearance | 1.5mil | 3mil | 1.5mil | |||
Min Solder Mask Dam | 3mil | 8mil | 3mil | |||
Min Legend Width/Height | 4/23mil | 4/23mil | 4/23mil | |||
Strain Fillet Width | / | 1.5±0.5mm | 1.5±0.5mm | |||
Bow &Twist | 0.003 | / | 0.0005 | |||
PCB Lead Time | ||||
Layer | Quick Turn/ Usual Time | Mass Production | ||
2L | 24hours /4 days | 8-10 days | ||
4L | 48hours /5 days | 10-12 days | ||
6L | 72hours /6 days | 12-14 days | ||
8L | 72hours /7 days | 16-18 days | ||
10L | 96hours /8 days | 18-20 days | ||
≥12L | 96hours /10 days | 18-20 days | ||
TOPFAST ELECTRONIC LIMITED is a PCB manufacturer providing PCB industry solutions for customers in the field of prototypes and small volumes.
With high quality and on time delivery product, we won the market's wide acclaim. Wewill continue to focus on customer satisfaction, along with "high quality"and "fastdelivery", the company will become an electronic circuit service provider worthy of customer trust.
