Product Overview
Description
Company Profile
As a national high-tech enterprise, ShangHai YingTong Electric Co., Ltd, since 2009, located in Songjiang District of Shanghai, covering 10,000 m2, is a professional science and technology enterprise engaged in R&D, production, and sales of products of power electronics and power automation technology. The Company focuses on smart power grid, power quality, power automation, power saving, and new energy power generation. On the aspects of energy saving and consumption reduction, improvement of power grid safety and stability, and improvement of power quality, the Company independently develops multiple series products in three fields, i.e. power quality and power safety, power saving, and power automation, which have been applied to the power, industrial, petroleum and other key energy consumption fields.
Our company focus on sales and service of Active Power Filter(APF), Static Var Generator(SVG), 3 phase load balancer, hybrid reactive power compensation cabinet. In addition to the main products, we also provide customized services such as scheme design, product customization, equipment maintenance and other customized services.
Active Power Filter APF
YTPQC-APF Active power filters from Shanghai Yingtong are the ultimate answer to tough power quality problems caused by harmonics, load unbalance and reactivepower demand for all applications by all types of customers. They can be installed in LV networks and in MV networks through the use of a suitable coupling transformer.
Shanghai Yingtong active power filter YTPQC-APF is a perfect and comprehensive solution to the power quality issues of power grid, such as harmonic wave, reactive power and three-phase load unbalance. YTPQC-APF active power filter which is in parallel to power grid can detect the harmonic wave in power grid in time, generate the reverse-phase compensation current through the converter and dynamically filter the harmonic wave in power grid. The operation of YTPQC-APF active power filter is unaffected by multifarious load forms and power grid structures. And it will not produce harmonic oscillation along with the system, thus perfectly realizing harmonic control under diverse loads.
YTPQC-APF active power filter can fully accomplish dynamic reactive compensation, control the capacitor switching and ultimately heighten the power factor of power grid. Meanwhile, YTPQC-APF has the function of controlling the three-phase load current unbalance, thus comprehensively handling various power quality matters in power grid.
YTPQC-APF Data Sheet
Item | Performance Index |
Rated input voltage | 220V/400V/480V/690V ±15% |
Rated frequency | 50Hz/60Hz±5% |
Circuit Topology | Three level inverter IGBT |
Power Grid Structure | 3 phase 3 wire or 3 phase 4 wire |
Rated capacity of modular | 15A,25A,30A,50A,75A,100A,150A |
Switching Frequency | 25.6kHz |
Response Time | ≤5ms |
Compensation Mode | (1) Reactive power (2) Harmonics (3) 3 Phase load imbalance |
Effect of Power Factor Correction | COSΦ≥0.99(after compensation) |
Effect of 3 phase balancing | ≤5% |
Harmonic mitigation performance | 2nd to 50th odd order Harmonics |
Effect of Harmonic mitigation | THDi≤5% after systematic control |
Active loss of system | <2.5% |
Controller | DSP+FPGA |
Control Algorithm | Self-adaptive control algorithm |
Communications | Modbus communication protocol/ RS485 and Can Bus are used for communication interface, which supports mobile App. |
Certificate | CE,Type test report |
Ambient Temperature | -20~55℃ |
Relative humidity | Maximum 95%, without condensation |
Altitude | ≤1,500m at rated capacity |
