Road machinery Crawler Bulldozer in Brazil 160HP 180HP wheel bulldozer price

Road machinery Crawler Bulldozer in Brazil 160HP 180HP wheel bulldozer price

Category: Bulldozers >>>
Supplier: Xiamen,LTMG,co.,ltd

Price:$33,000.00 - $33,550.00

Price in USD:Details

Quantity:

Product Overview

Description

China New 160HP Dozer Bulldozer Small Wheel Bulldozer Price

LTMG's best-seller worldwide, this is a medium-duty workhorse that comes off the factory line in various configurations for specific work environments, e.g., desert, swamp, forest, high altitude, etc.

It has a Tier IIIB Cumm-ins engine for European markets and optional engines (Weichai and Shangchai) for other markets.

The T160 provides high performance with strong reliability.

Model		T160
Item		160hp Bulldozer
Engine	Model & type	Shangchai SC11CB184G2B1/Weichai WD10G178E25;
	Model & type			water-cooled, in-line, 4-stroke injection direct
		Horsepower	Gross power: 131/175/1850 kW/HP/rpm //
		Horsepower		Net power: 120/160/1850 kW/HP/rpm
		Number of cylinders	6-126 x 130 mm (bore x stroke)
		Piston displacement	9.726 L
		Min. fuel consumption	214 g/kW·h
		Maximum torque	765 N·m@1300 rpm
Power transmission system	Torque converter	3-element, 1 stage, 1 phase
		Transmission	Planetary gear type, power-shift, forced lubrication
		Main drive	Spiral bevel gear, single-stage speed reduction,
		Main drive		splash lubrication
		Steering clutch	Lubricated, multi-disc, spring loaded, hand hydraulically separated, inter-linking with steering brake
		Steering brake	Lubricated, floating band structure, foot brake
		Steering brake		with hydraulic booster
		Final drive	2-stage speed reduction of spur gear, splash lubrication
Travel speed	Gear	1st	2nd	3rd
		Forward	0~3.29 km/h	0~5.82 km/h	0~9.63 km/h
		Reverse	0~4.28 km/h	0~7.59 km/h	0~12.53 km/h
Undercarriage system	Type	Sprayed beam, suspended structure of equalizer
		Carrier rollers	2 each side
		Track rollers	6 each side
		Track type	Assembled, single-grouser
		Width of track shoes	510 mm
		Pitch	203.2 mm
Hydraulic System	Maximum pressure	14 MPa
		Pump type	Gear pump
		Discharge	243 L/min
		Bore of working cylinder × no.	110 mm × 2
Blade	Blade Type	Straight-tilt	Angle	U- Blade
		Dozing capacity	4.5 m 3	4.4 m 3	5.0 m 3
		Efficiency (Theoretical value 40 m)	225 m 3 /h	225 m 3 /h	250 m 3 /h
		Blade width	3388 mm	3970 mm	3556 mm
		Blade height	1149 mm	1040 mm	1120 mm
		Maximum drop below ground	540 mm	530 mm	540 mm
		Lifting height of blade	1095 mm	1110 mm	1095 mm
Riipper (Optional)	Maximum digging depth of 3-shank ripper	572 mm
		Maximum lift above ground	592 mm
		Weight of 3-shank ripper	1667kg

Machine application

LTMG always treat after-sale service important as the same as product quality.
LTMG grants our clients a twelve-month-period or 2000-hours warranty for any machine purchased from us.
LTMG can also help clients coordinate with trained service personnel to provide you detailed and extensive knowledge about your specific machine. With our technical advises, your machine service life can be significantly prolonged and sustained with high capacity.
