Share on (1600657474074):


Price:$31,000.00 - $32,000.00

Quantity:


Product Overview

Description



STC55D*1000
STC55D*1500
block type
Disk type parts ｜ 550mm
Disk type parts ｜ 550mm
Shaft type parts ｜ 360mm
Shaft type parts ｜ 360mm
Maximum center distance
1050 mm
1500 mm
Bed and horizontal inclination
Linear Guide
Linear Guide
45 ° inclined layout,
45 ° inclined layout,
Maximum stroke
X axis: 320 mm Z axis: 1200 mm
X axis: 320 mm Z axis: 1600 mm
Recommended servo motor power
X axis: 1.5KW Z axis: 1.8KW
X axis: 1.5KW Z axis: 1.8KW
positioning accuracy
X axis: 0.016 mm Z axis: 0.020 mm
X axis: 0.016 mm Z axis: 0.020 mm
Repetitive positioning accuracy
X axis: 0.003 mm Z axis: 0.005 mm
X axis: 0.003 mm Z axis: 0.005 mm
Circularity
0.005 mm
0.005 mm
Hydraulic tailstock sleeve diameter/stroke
∮58mm / 100mm
∮75mm / 100mm
Hydraulic tailstock center taper
MT4#
MT5#
Overall dimension mm
3250 x 1900 x 1900
3250 x 1900 x 1900
Net weight
4200Kg
5200Kg








Certifications








Q1:Is your company a factory or trading company?
A1:We are factory and have more than 12 years production experience. So we can offer the best price for you.

Q2:Do you have CE certification?
A2:Yes, we have CE certification, the quality of our machines is guaranteed.

Q3:What's the main products of your company?
A3:The leading products are CNC milling machines, CNC lathes, CNC special machine tools, a series of multi-function drilling and milling machines, light milling machines, radial drills, forging equipment and more than ten varieties. The products are beautiful in shape, stable in performance and reliable in quality.

Q4:How can I choose the most suitable machines ?
A4:Please tell us your requirement of the machine, or you can also send us the products drawing, our engineer can help to choose the best model for you.

Q5:What's the MOQ?
A5:1 set. We will offer you’re a better price if you order more.
