GEYA GYAG20 Q40 NA Inductive Proximity Sensor Detection Switch elevator door Industrial automation
- Category: >>>
- Supplier: Zhejiang Geya Electrical Co. Ltd.
Share on (1600659366148):
Product Overview
Description
This link price is only for GYAG20-Q40-NA.if you need other specification，please feel free to contact us！
Product Description
The proximity switch has a difference between two wires and three wires. Three wire proximity switch is divided into NPN type and
PNP type. They have different wiring modes.
The wiring of the two-wire proximity switch is relatively simple. The proximity switch is connected in series with the load and
then connected to the power supply.
Wiring of three-wire proximity switch: red (brown) wire is connected to the positive end of the power supply; the blue wire is
connected to the 0V end of the power supply; the yellow (black) line is the signal line, which should be connected to the load.
The other end of the load shall be connected to the positive end of the power supply for the NPN-type proximity switch, and to the
0V end of the power supply for the PNP-type proximity switch.
A load of proximity switch can be a signal lamp, relay coil, or digital input module of PLC.
PNP type. They have different wiring modes.
The wiring of the two-wire proximity switch is relatively simple. The proximity switch is connected in series with the load and
then connected to the power supply.
Wiring of three-wire proximity switch: red (brown) wire is connected to the positive end of the power supply; the blue wire is
connected to the 0V end of the power supply; the yellow (black) line is the signal line, which should be connected to the load.
The other end of the load shall be connected to the positive end of the power supply for the NPN-type proximity switch, and to the
0V end of the power supply for the PNP-type proximity switch.
A load of proximity switch can be a signal lamp, relay coil, or digital input module of PLC.
Specification
item | value |
Model Number | GYAG20-Q40-NA |
Type | Non-screen shield type |
Place of Origin | China |
Zhejiang | |
Brand Name | GEYA |
Usage | Detection distance |
Theory | Detect objects with magnetism |
Output | NPN/PNP NO(NC) |
Description | Proximity Sensor |
Voltage range | DC10-30V |
Max operating Distance | 20mm |
Specifical | NPN DC 3WIRE NO |
