HI TARGET TS7 pro Survey Land Surveying Gps Rtk Cheap Price Gnss Receiver gnss rtk base and rover
HI-TARGET TS7 pro Survey Land Surveying Gps Rtk Cheap Price Gnss Receiver gnss rtk base and rover
HI-TARGET TS7 pro Survey Land Surveying Gps Rtk Cheap Price Gnss Receiver gnss rtk base and rover
HI-TARGET TS7 pro Survey Land Surveying Gps Rtk Cheap Price Gnss Receiver gnss rtk base and rover
HI-TARGET TS7 pro Survey Land Surveying Gps Rtk Cheap Price Gnss Receiver gnss rtk base and rover

HI TARGET TS7 pro Survey Land Surveying Gps Rtk Cheap Price Gnss Receiver gnss rtk base and rover

Share on (1600660475905):


Price:$2,761.00

Quantity:


Product Overview

Description











GNSS configuration
Number of channels: 660
BDS: B1, B2, B3 .
GPS: L1, L2. L5
GLONASS: L1. L2
GALILIEO: E1. E5a, E5b
QZSS: support
SBAS: support
Output format
ASCII: NMEA-0183,binary code
Positioning output frequency
1Hz~20Hz
Static data format
GNS, Rinex dual format static data
Differential format
CMR，RTCM2.X, RTCM3.0, RTCM3.2
Network mode
VRS, FKP, MAC; support NTRIP protocol
System Configuration
Operating system
Linux operating system
Start Time
3 seconds
Data storage
Built-in 8GB ROM, support automatic cycle storage of static data
Accuracy and reliability[1]
RTK positioning accuracy
Plane: ±(8+1x10-6D) mm (D is the distance between the measured points)
Elevation: ±(15+1x10-6D) mm (D is the distance between the measured points)
Static positioning accuracy
Plane: soil (2.5+0.5x10-6D) mm (D is the distance between the measured points)
Elevation: soil (5+0.5x10-6D) mm (D is the distance between the measured points)
DGPS positioning accuracy
Plane Accuracy: +0.25m+1ppm; Elevation Accuracy: +0.50m+ 1ppm
SBAS positioning accuracy
0.5m
Initialization time
<10 seconds
Initialization reliability
> 99.99%
Communication unit
I/O ports
USB Type C interface, SMA interface,
Built-in eSIM
Including 3 years of Internet access fee, you can connect to the Internet without inserting a card
WiFi communication
802.11 a/b/g/n access point and client mode for WiFi hotspot service
Bluetooth communication
Bluetooth4.2/2.1+EDR,2.4GHz
Built-in radio
Built-in transceiver integrated radio
Power: 0.5W/1W/2W adjustable
Frequency: 410MHz~470MHz
Protocol: HI-TARGET, TRIMTALK450S, TRIMMARKM, TRANSEOT, SOUTH
Number of channels: 116 (16 of which are configurable)
Sensor
Electronic bubble
Achieve smart centering
Inclination measurement
Built-in high-precision inertial navigation, automatic attitude compensation, no correction, anti-magnetic interference,
point-to-point measurement, accuracy of 3 cm.
User Interface
Button
One button
LED indicator light
satellite light, signal light
Functional application
Advanced Features
NFC IGRS, WebUI interaction, U disk firmware upgrade
Smart application
Intelligent base station, intelligent voice, function self-test, intelligent CORS
Remote Service
Message push, online upgrade, remote control
Cloud service
Device management, location services, collaborative work, data analysis
Physical properties
Host battery
Built-in high-capacity lithium battery 6800mAh/7.4V, network mobile station working time 10 hours[2]
Support fast charge
Support USB charging. Support power bank charging.
Size
φ132mmx67mm
Weight
Less than 0.82kg
Power consumption
4.2W
Material
The shell is made of magnesium alloy material
Environmental characteristics
Dustproof and waterproof
IP68
Anti-drop
Anti-2 meters high measuring rod natural drop
Relative humidity
100% non-condensing
Operating temperature
-30°C~+70°C
storage temperature
-40°C~+80°C














Q:WHAT'S THE DELIVERY TEMRS?
A:EXW，FOB，CFR，CIF.

Q:WHAT'S THE SAMPLES POLICY?
A:We can supply samples if we have parts in stock.

Q:WHAT'S THE LEAD TIME?
A:The lead time for the current instrument in mass production is 15 days the new product or the first batch is 30-60 days.

Q:WHY DID YOU CHOOSE US?
A:Known as a professional company for 40 years,SINCON commits to provide the high quality of products and services to our customers.

Q:WHAT ABOUT THE AFTER-SALE SERVICE?
A:We have our professional quality control team to control all the production professes and we can give the prompt response for the customer complaint.
