Valves C700 220V 24V 12V AC DC 2 way 3 way Motorized Actuator Fan Coil DN15 DN25 motorized electric valve
- Category: >>>
- Supplier: Shanghai Best Automation Technology Co. Ltd.
Share on (1600660723350):
Product Overview
Description
VR
Product Overview
Name | Nominal diameter | Valve body material | Nominal pressure | Suitable temp. | ||||
Electric valve | DN15-25 | Cast Brass | 16 | ＜95℃ | ||||
Others can customize according to your requirements | ||||||||
Key Specifications/Special Features:
01.General purpose and be exclusively used for HVAC products
02.Valve body material : Cast Brass ( code: T)
03.Seal material of valve seat: normal--- POM(code: M), special requirement needs customization
04. Packing: normal---nitrile rubber (NBR, code: N)
Special---silicone rubber (code: G) or customer's specification.
05. Applicable ambient temp: -15～75℃
06.Single stroke time: 16s(normal), 8~30s (custom)
07.Zero leakage, with manual device, visual valve position indicator
08.Valve core is globe type, moves up & down to realize the function
09.Medium flow direction should be consistent with the arrow direction;Can be mounted at any angle
10.valve position limit switch, full open or fully closed, power off immediately, energy-saving, safe, long life span
11.Voltage normal: AC220/AC110/AC24/AC12V 50/60Hz, allowable fluctuation ±10%, customization accepted, currently no DC series
02.Valve body material : Cast Brass ( code: T)
03.Seal material of valve seat: normal--- POM(code: M), special requirement needs customization
04. Packing: normal---nitrile rubber (NBR, code: N)
Special---silicone rubber (code: G) or customer's specification.
05. Applicable ambient temp: -15～75℃
06.Single stroke time: 16s(normal), 8~30s (custom)
07.Zero leakage, with manual device, visual valve position indicator
08.Valve core is globe type, moves up & down to realize the function
09.Medium flow direction should be consistent with the arrow direction;Can be mounted at any angle
10.valve position limit switch, full open or fully closed, power off immediately, energy-saving, safe, long life span
11.Voltage normal: AC220/AC110/AC24/AC12V 50/60Hz, allowable fluctuation ±10%, customization accepted, currently no DC series
