Manufactory Weichai Engine Single/Three Phase Low Rpm Alternator 250 Kva 200 Kw Silent Diesel Engine Generator With Ats
- Category: >>>
- Supplier: Shandong Huali Electromechanical Co. Ltd.
Share on (1600660974632):
Product Overview
Description
Company Profile
Product Description
Generators set model | HL200GF | Speed mode | Electronic |
Prime power（KW） | 200 | Full load fuel consumption rate（g/kwh） | 202 |
Standby power（KW） | 220 | Fuel model | Normal temperature |
Genset capacity (KVA) | 250 | Coolant flow（m3/min） | / |
Related speed (RPM) | 1500 | Gas volume（m3/min） | / |
Related voltage (V) | 400 | Smoke exhaust（m3/min） | / |
Rated current (A) | 360 | Speed mode | / |
Related frequency(Hz) | 50 | cooling method | Closed water cooling |
Rated power factor | 0.8 | Oil capacity(L) | 27.6 |
Phase | 3 | Coolant capacity (L) | 11.1 |
Reference weight（Kg） | 1700 | reference weight（Kg） | 650（Dry weight） |
Reference size (L × W × H) | 2570*960*1550（mm） | Alternator model | HLF-200 |
Engine model | NTA855-GA | Rated voltage (V) | 400 |
Engine related power（KW） | 220 | Rated frequency(Hz) | 50 |
Engine standby powe（KW） | 240 | Rated speed(RPM) | 1500 |
Engine structural features | Four-stroke, turbocharged | Power factor | 0.8 |
Cylinders / arrangement | 6 cylinders/In-line | Phase and wiring | Three phase Y type |
Bore × stroke（mm） | 114×145 | efficiency(%) | 95.19 |
Displacement(L) | 5.9 | Excitation method | Brushless excitation |
Compression ratio | 16.6：1 | Insulation class | H |
Start method | Electric | Protection level | IP21 |
Searching table
Diesel Generator Set Searching Table | ||||||
Details Images
Company Profile
Shandong Huali Electromechanical Co., Ltd. which is located in Jining city, Shandong province, was established in 1999, covering an area of 300 thousand square meters,with a registered capital of USD 43 million.
Our company mainly produce all kinds of generator sets, fog cannon and AGV robot. We have 600 employees including 80 engineers and technicians, 6 ordinary producing lines, 10 high precision AGV robot producing lines, and we own more than 300 sets NC equipment, and one national standard testing center. We are honored as “Abide by contract and Keep faith” enterprise. Our products are authorized by ISO9001 certificate, CE certificate, CCC certificate, etc. Through the development during tens of years, our company has become the leading company of generator set industry in north of China and the leading company of fog cannon industry in China. We will continuously create value for customers, and achieve the common goal of win-win cooperation.
Our company mainly produce all kinds of generator sets, fog cannon and AGV robot. We have 600 employees including 80 engineers and technicians, 6 ordinary producing lines, 10 high precision AGV robot producing lines, and we own more than 300 sets NC equipment, and one national standard testing center. We are honored as “Abide by contract and Keep faith” enterprise. Our products are authorized by ISO9001 certificate, CE certificate, CCC certificate, etc. Through the development during tens of years, our company has become the leading company of generator set industry in north of China and the leading company of fog cannon industry in China. We will continuously create value for customers, and achieve the common goal of win-win cooperation.
FAQ
Q1: How long is your delivery time?
A1: It is according to the model and quantity.
Generally it is 3-5 days if the machines are in stock.
It will be 15-30 days if you want to customize the machines.
Q2: Do you provide samples? Is it free or extra?
A2: Yes, we could offer you the sample machine.
But it's not free. You need to pay for the sample and the cost of freight.
Q3: What is your terms of payment?
A3: We accept T/T, Western Union, Alibaba Trade Assurance.
A1: It is according to the model and quantity.
Generally it is 3-5 days if the machines are in stock.
It will be 15-30 days if you want to customize the machines.
Q2: Do you provide samples? Is it free or extra?
A2: Yes, we could offer you the sample machine.
But it's not free. You need to pay for the sample and the cost of freight.
Q3: What is your terms of payment?
A3: We accept T/T, Western Union, Alibaba Trade Assurance.
