3/4' DN20 Pulse/485 Signal Electromagnetic Flowmeter Liquid Sewage Water Metering 5 150LPM Stainless Steel LCD Display
- Category: >>>
- Supplier: Foshan Shunde Zhongjiang Energy Saving Electronics Co. Ltd.
Share on (1600661057172):
Product Overview
Description
3/4'' DN20 Pulse/485 Signal Electromagnetic Flowmeter Liquid Sewage Water Metering 5-150LPM Stainless Steel LCD Display
DISPLAY + CONTROL + 485 REMOTE TRANSMISSION
#1 REAL-TIME DISPLAY flow / temperature / velocity
#2 the velocity value CONTROL, the total quantitative CONTROL
#3 485 REMOTE TRANSMISSION
SPECIFICATION:
| Model No. | ZJLCD-DN20 (SUS) |
| Pipe Connection | 3/4'' (DN20) |
| Operating Voltage | 10-30VDC |
| Max Working Current | 60mA ( 30VDC ) |
| Measuring the Liquid | Water or other chemical liquid |
| Reaction Time | Real-time |
| IP Grade | IP65 |
| Working Environment Temperature | -10℃ ~70℃ |
| Working Pressure | 5kg/cm2 |
| Setting Range of Instantaneous Flow (LPM) | 0 ~ 999.99 |
| Setting Range of Total Flow (FTM) | 0 ~ 999999 |
| Instantaneous Flow Control Output | NPN (Max 150mA) |
| Total Flow Control Output | NPN (Max 150mA) |
SEA SENSOR
| PRODUCT NAME | PVC TURBINE FLOW METER |
| MATERIAL | UPVC |
| PIPE CONNECTION | DN25-80 |
| POWER SUPPLY | BATTERY POWERED |
