Wholesale Inductive Proximity Switch Sensor Capacitive Dc Proximity Sensor
Wholesale Inductive Proximity Switch Sensor Capacitive Dc Proximity Sensor

Wholesale Inductive Proximity Switch Sensor Capacitive Dc Proximity Sensor

Share on:


Price:
Price in USD:Details

Quantity:


Product Overview

Description



Wholesale Inductive Proximity Switch Sensor Capacitive Dc Proximity Sensor


Products Description


Model
Output type
Mounting type
Sensing
Effective
Frequency
Load
Protection
Code
TL-12N(NC)4B
NPN NO(NC)
Non-flush
4mm
3.2mm
400Hz
100mA
IP66(IEC)
C0021TL01
TL-12P(PC)4B
PNP NO(NC)
Non-flush
4mm
3.2mm
400Hz
100mA
IP66(IEC)
C0021TL01
TL-18N(NC)5B
NPN NO(NC)
Flush
5mm
4mm
400Hz
100mA
IP66(IEC)
C0026TL01
TL-18P(PC)5B
PNP NO(NC)
Flush
5mm
4mm
400Hz
100mA
IP66(IEC)
C0026TL01
TL-18N(NC)8B
NPN NO(NC)
Non-flush
8mm
6.4mm
200Hz
100mA
IP66(IEC)
C0028TL01
TL-18P(PC)8B
PNP NO(NC)
Non-flush
8mm
6.4mm
200Hz
100mA
IP66(IEC)
C0028TL01
TL-30N(NC)10B
NPN NO(NC)
Flush
10mm
8mm
200Hz
100mA
IP66(IEC)
C0038TL01
TL-30P(PC)10B
PNP NO(NC)
Flush
10mm
8mm
200Hz
100mA
IP66(IEC)
C0038TL01
TL-30N(NC)15B
NPN NO(NC)
Non-flush
15mm
12mm
100Hz
100mA
IP66(IEC)
C0040TL01
TL-30P(PC)15B
PNP NO(NC)
Non-flush
15mm
12mm
100Hz
100mA
IP66(IEC)
C0040TL01


Type
DC 3-wire
Flush
Non-flush
Flush
Non-flush
Flush
Non-flush
Model
TL-12N(C)2B
TL-12N(C)4B
TL-18N(C)5B
TL-18N(C)8B
TL-30N(C)10B
TL-30N(C)15B
TL-12P(C)2B
TL-12P(C)4B
TL-18P(C)5B
TL-18P(C)8B
TL-30P(C)10B
TL-30P(C)15B
Dimension
M12×43mm
M18×48mm
M30×58mm
Detected object
Magnetic metal (detection distance decreases when it’s non-magnetic metal)
Stipulate distance
2mm
4mm
5mm
8mm
10mm
15mm
Sensing distance
0~1.6mm
0~3.2mm
0~4.0mm
0~6.4mm
0~8.0mm
0~12.0mm
Frequency
≤600Hz
≤400Hz
≤400Hz
≤200Hz
≤200Hz
≤100Hz
Output current
≤100mA
Power supply
DC 10~30V
Hysteresis
Less than 10% of the stipulate distance
Control output
Pure resistance load≤100mA, induction load≤50mA
Voltage drop
≤2V (At DC 24V 100mA)
Leakage current
≤0.5mA(At DC 24V)
Insulation
100MΩ (At DC 500V)
Dielectric
AC 1000V 1min (At 50/60Hz)
LED
Yellow
Protection
IP66(IEC)
Working
-25℃~70℃
Cable length
Standard 2m










Promotion




Recommend Products






Company Profile








Certifications




Exhibition






FAQ


Q1.Can you produce according to the samples or drawings?
Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

Q2.What is your terms of payment?
Usually,we accept T/T, irrevocable L/C at sight. For regular orders, Terms of payment 30% deposit, full payment before delivery the goods.

Q3.What is the lead time?
For standard models, lead time is about 3~5 days after order confirmed and payment received.
For OEM orders, the delivery is about 2~3 weeks after data confirmed and payment received.

Q4.What is your terms of packing?
Under TOKY brand, the standard packing is 1pc item in a colour box or brown inner box, then into standard export carton.
For OEM order, usually 1pc item in a brown inner box, then into standard export carton.

Q5.What is your terms of delivery?
We accept EXW,FOB,CIF,etc. You can choose the one which is the most convenient or cost effective for you.

Q6.How to solve the quality problems after sales?
Take photos or videos of the problems and send to us.
We will make a satisfied solution for you within 24 hours after we confirm the problems.

Q7.Do you have any MOQ limit for the order?
Low MOQ, 1pc for sample checking is available.

Q8.Is it OK to print my logo on the product?
Yes, OEM service is available.
Please confirm with our sales team formally before production and confirm the design firstly based on our sample.

Q9.Are you manufacturer or trading company?
We are manufacturer for over 30 years. Welcome to visit our factory at anytime.
