Product Overview
Description
Products Description
Pixel array | 256*360 |
Module Size | 35*23mm |
Window Size | 19.9*14.5mm |
Operating current: Sampling mode | <100mA |
Fingerprint template capacity | 100 pieces |
Data connect | USB&UART |
Power on time | Less than 100ms |
FLASH capacity | 1M byte(Maximum storage capacity is 32M) |
Interface | TTL（12pin, 0.5mm pitch） |
Baud rate | 115200bps |
Storage temperature | -40℃ - 85℃ |
Operation temperature | -20℃ - 65℃ |
Relative humidity | 0% - 85% |
FAR | <0.001% |
FRR | <1.5% |
Touch Effective output level | Low effective |
Supported operating system | Embedded Android，Linux，WinCE and Windows OS |
