  • Factory Directly PLC Splitter Device LC/APC 2x4 Insertion /LGX /Cassette type Fiber Optic fiber optic equipment
Factory Directly PLC Splitter Device LC/APC 2x4 Insertion /LGX /Cassette type Fiber Optic fiber optic equipment
Factory Directly PLC Splitter Device LC/APC 2x4 Insertion /LGX /Cassette type Fiber Optic fiber optic equipment
Factory Directly PLC Splitter Device LC/APC 2x4 Insertion /LGX /Cassette type Fiber Optic fiber optic equipment
Factory Directly PLC Splitter Device LC/APC 2x4 Insertion /LGX /Cassette type Fiber Optic fiber optic equipment
Factory Directly PLC Splitter Device LC/APC 2x4 Insertion /LGX /Cassette type Fiber Optic fiber optic equipment
Factory Directly PLC Splitter Device LC/APC 2x4 Insertion /LGX /Cassette type Fiber Optic fiber optic equipment
Factory Directly PLC Splitter Device LC/APC 2x4 Insertion /LGX /Cassette type Fiber Optic fiber optic equipment

Factory Directly PLC Splitter Device LC/APC 2x4 Insertion /LGX /Cassette type Fiber Optic fiber optic equipment

Share on (1600665349845):


Price:$5.00 - $6.00

Quantity:


Product Overview

Description











Factory Directly PLC Splitter Device LC/APC 2x4 Insertion /LGX /Cassette type Fiber Optic fiber optic equipment


Features
* Low Insertion loss
* Low PDL
* Compact Design
* Good channel-to-channel uniformity
* Wide Operating Wavelength: From 1260nm to 1650nm
* Wide Operating Temperature: From -40°C to 85°C
* High Reliability and Stability

Application
* Fiber to The Home (FTTH)
* Passive optical networks (PON)
* Local Area Networks (LAN)
* Cable Television (CATV)
* Test Equipment








Item
2x4
Operating Wavelength(nm)
1260-1650
Fiber Type
G657A1 or as customers' order
Connector
LC
Ferrule section
APC
Insertion loss(dB)
≤13.8
Loss uniformity(dB)
≤1.2
Return Loss(dB)
≥55
Polarization Dependent Loss(dB)
≤0.25
Directivity(dB)
≥55
Temperature correlation loss
≤0.5
-40～85℃(dB)
Size(mm)(LxWxH)
60×7×4
Working Temperature(℃)
-40～85


Parameter
Specification
Operating Wavelength (nm)
1260 ~ 1650
Type
1x4
1x8
1x16
2x4
2x8
2x16
1x32
2x32
1x64
Insertion Loss (dB) Max. *
<7.3
<10.4
<13.5
<7.6
<11.2
<14.5
<16.2
<18.2
<20.5
Uniformity (dB) Max.*
<0.8
<1.0
<1.5
<1.0
<1.5
<2.0
<2.0
<2.5
<2.5
PDL(dB)Max.*
<0.2
<0.2
<0.3
<0.3
<0.3
<0.4
<0.3
<0.4
<0.3
Directivity (dB) Min *
55
Return Loss (dB) Min *
55(50)
Operating Temperature (°C)
-5~ +75
Storage Temperature (°C)
-40 ~ +85
Fiber length
1m or custom length
Fiber Type
SMF-28e fiber or customer specified
Connector Type
Custom specified
Power Handling (mW)
300















1. Can we get a lower price? Any Discount?
Yes, price is not a problem, everything could be negotiated based on the quantity.

2. Can I get a free sample?
Yes,send inquiry,you will get free sample.

3. We are new in this PON fields, can you help me and recommend me some items?
Yes, of course. It is our pleasure to help you with it.
You only need to offer us more details about your application.

4. What is your MOQ?
No MOQ for any sample test.

5. OEM/ODM Service is available?
Yes, we have strong ability to offer customers ODM&OEM products of highest quality.
And it will require the MOQ.

6. For Trade Terms, such as payment and leadtime.
* Payment Terms: We mainly support T/T bank transfer,Paypal and Western Union
* Price Terms: EXW FOB CIF Shenzhen
* Shipping Methods: EMS, DHL, Fedex, TNT, UPS, by sea or your own shipping agent
* Leadtime: Sample order 3-7work days; Bulk order 15-25work days(after your payment)

7. How about the Warranty?
There are 1 Year for the warranty.
While the warranty is not responsible for those broken by violence or updated with other brands.
