ALD 1.70mm digital flexo photopolymer printing plate
- Category: Printing Plates >>>
- Supplier: Suzhou,Aolide,Co.,Ltd.
Share on:
Product Overview
Description
AOLIDE digital flexographic printing plate series
| Type | AD394 -Ⅰ | AD394 -Ⅱ | AD318 -Ⅰ | AD284 -Ⅰ | AD254 -Ⅰ |
| Plate thickness (mm) | 3.94 | 3.94 | 3.18 | 2.84 | 2.54 |
| Durometer (Shore A) | 43-45 | 38-36 | 37-39 | 45-48 | 56 |
Recommended relief depth (mm) | 1.8-2.0 | 1.8-2.0 | 0.9-1.5 | 1.0-1.4 | 1.0-1.2 |
| Image reproduction | 2~98% | 2~98% | 2-98% | 2~98% | 2-98% |
Maximum line, line/inch | 100 | 100 | 120 | 120 | 133 |
| Minimum isolated line | 0.20mm (0.008inch) | 0.20mm (0.008inch) | 0.175mm (0.007inch) | 0.15mm (0.006inch) | 0.15mm (0.006inch) |
| Minimum isolated dot | 0.40mm (0.016inch) | 0.40mm (0.016inch) | 0.25mm (0.01inch) | 0.25mm (0.01inch) | 0.25mm (0.01inch) |
| Compatible ink | Suitable for water and alcohol-based ink, incompatible with oil-based ink,hydrocarbon solvent or the ink containing ethyl acetate of more than 25% | ||||
| Main application | Label,Flexible package,Carry bag, Folded paper box,Napkin,Beverage package | ||||
| Type | AD170 -Ⅰ | AD170 -Ⅱ | AD114 -Ⅰ | AD114 -Ⅱ |
| Platethickness (mm) | 1.70 | 1.70 | 1.14 | 1.14 |
| Durometer (Shore A) | 60-62 | 70-72 | 69-72 | 75-76 |
| Recommended relief depth (mm) | 0.7-0.9 | 0.7-0.9 | 0.6-0.7 | 0.6-0.7 |
| Image reproduction | 1~98% | 1~98% | 1~98% | 1~98% |
| Maximum line, line/inch | 150 | 150 | 150 | 150 |
| Minimum isolated line | 0.15mm (0.0059inch) | 0.10mm (0.004inch) | 0.10mm (0.004inch) | 0.10mm (0.004inch) |
| Minimum isolated dot | 0.20mm (0.0079inch) | 0.20mm (0.0079inch) | 0.20mm (0.0079inch) | 0.20mm (0.0079inch) |
| Compatible ink | Suitable for UV ink, some tested solvent inks, besides water and alcohol-based ink | Suitable for water , alcohol-based ink and UV-ink | ||
| Main application | Film,Label,flexible package, Carry bag,Folded paper box , Beverage package | Film,Label,flexible package, Beverage package printing and varnish | ||
Size of AOLIDE digital flexographic printing plate
| Type | AD394 -Ⅰ AD394 -Ⅱ | AD318 -Ⅰ | AD284 -Ⅱ | AD254 -Ⅰ | |
| Plate thickness (mm) | 3.94 | 3.18 | 2.84 | 2.54 | |
| sizemm(inch) | 762×1016 (30×40) | √ | √ | √ | √ |
| 1067×1524 (42×60) | √ | √ | √ | √ | |
| 1067×2032 (42×80) | √ | √ | √ | √ | |
| 1200×2032 (47.2×80) | - | - | - | - | |
| 1270×2032 (50×80) | √ | √ | √ | √ | |
| Type | AD170 -Ⅰ | AD170 -Ⅱ | AD114 -Ⅰ | AD114 -Ⅱ | |
| Plate thickness (mm) | 1.70 | 1.70 | 1.14 | 1.14 | |
| sizemm(inch) | 762×1016 (30×40) | √ | √ | √ | √ |
| 1067×1524 (42×60) | √ | √ | √ | √ | |
| 1067×2032 (42×80) | √ | √ | √ | √ | |
| 1200×2032 (47.2×80) | - | - | - | - | |
| 1270×2032 (50×80) | √ | √ | √ | √ | |
Technical specification of AOLIDE digital flexographic printing plate
| Type | AD394 -Ⅰ | AD394 -Ⅱ | AD318 -Ⅰ | AD284 -Ⅰ | AD254 -Ⅰ |
Plate thickness( mm) | 3.94 | 3.94 | 3.18 | 2.84 | 2.54 |
| Back Exposure(seconds) | 35-60 | 50-70 | 25-75 | 25-40 | 25-35 |
| Main Exposure(minutes) | 12-20 | 12-20 | 8-20 | 12-20 | 12-18 |
| Rinsing(minutes) | 5-8 | 5-8 | 5-7 | 5-8 | 5-8 |
| Drying(hours) | 1.5-2 | 1.5-2 | 1.5-2 | 1.5-2 | 1.5-2 |
Detackfying (minutes) | 5-8 | 5-8 | 5-7 | 5-8 | 5-8 |
Post exposure (minutes) | 5 | 5 | 5 | 5 | 5 |
| Type | AD170 -Ⅰ | AD170 -Ⅱ | AD114 -Ⅰ | AD114 -Ⅱ |
Plate thickness( mm) | 1.70 | 1.70 | 1.14 | 1.14 |
| Back Exposure(seconds) | 25-40 | 25-40 | 35-60 | 35-70 |
| Main Exposure(minutes) | 12-20 | 12-20 | 10-18 | 10-18 |
| Rinsing(minutes) | 5-7 | 5-7 | 5-7 | 5-7 |
| Drying(hours) | 1.5-2 | 1.5-2 | 1-1.5 | 1-1.5 |
Detackfying (minutes) | 5-8 | 5-8 | 5-7 | 5-8 |
Post exposure (minutes) | 5 | 5 | 5 | 5 |
Why Choose Us
Customer feedback
Packaging
FAQ
Q1:Can you provide samples?
A1:Yes, free samples in A3 size is available.
Q2:Do you test all your goods before delivery?
A2:Yes, we have a team keep testing goods before delivery.
Q3:Which port will the goods be shipped from ?
A3:Shanghai port, other port you want, please negotiate with us.
Q4:How much experience do you have ?
A4:We started to research and develop this product in 2004 and have served customers in more than 57 countries.
Q5:Can you produce the products as required ?
A5:Of course we can.
About Us
Suzhou Aolide was founded in 2006 by senior experts and scholars in the printing industry. Located in Suzhou, close to Shanghai Port, so the transportation is extremely convenient. Suzhou Aolide has modern workshops and specialized production lines and testing equipments, as well as a professional design and development team, industry senior management and technical personnel. At present, Aolide has developed into a first-class printing industry system supply provider in China.
Suzhou Aolide's business covers the design of flexographic plate-making schemes, technical consultation, the production and sales of plate-making equipment and printing materials. The company has provided product and service support to partners in more than 57 countries.
Suzhou Aolide always adheres to the business philosophy of "customers first, employees first, reputation first", and strives to provide domestic and foreign users with the most cost-effective products and the most satisfactory services. We adheres to the path of technological innovation and sustainable development, and strives to be a world-class system supply provider for the printing industry.
