Product Overview

Description



Product Description


The medium does not want to come into contact with the instrument measuring system, the diaphragm seal does not create dead space or areas that cannot be emptied and is suitable for sanitary systems.




Specification












Diameter：φ63mm，φ98mm

Stainless steel case and internal

Accuracy：1%，1.5%，2.5%

Liquid-filled as option with type plus "N"





DN
D(mm)
H(mm)
f
M
1"
50.5
48
3/8-24UNF2B
35
1.5"
50.5
48
3/8-24UNF2B
35
2"
64
48
3/8-24UNF2B
50
2.5"
77.5
48
3/8-24UNF2B
58


Threaded Process Connection
per Europe standard and viaous standard
DIN:SMS;IDF:APV-RJT
Note:when ordering，please specify detailed standard and dimension.




DIN 11851
DN
GAMPO SCALA RANGE
H
h
d
m
f（DN405）
25
0/6-40bar
44
21
63
20.5
Rd52x1/6
32
0-4-40bar
46
21
70
29
Rd58x1/6
40
0/0.25-40bar
47
21
78
36
Rd65x1/6
50
0/1.6-40bar
47
22
82
50
Rd78x1/6


SMS 681
DN
CAMPO SCALA RANGE
H
h
d
m
f（DN405）
1-1/2"
0/4-40bar
49.5
25
74
29
Rd60x1/6
2"
0/2.5-40bar
50.5
26
84
36
Rd70x1/6


Company Profile




WOFLY is a leading Manufacturer, Supplier and Exporter of a wide range of gas equipements, available under the brand name AFK. Wofly's success yields from high-quality, innovative products, exceptional customer service, and unequaled technical expertise in the gas& oil industry.

WOFLY offers an extensive line of components including tube fittings, control valves, shut-off and solenoid valves, pressure relief and regulators.Through the years we have learned how to properly match the gas regulation equipment with the application. Using the proper equipment for the job eliminates problems such as contamination, pressure variances, safety issues, and equipment mismatch.


FAQ


1. who are we?
We are based in Guangdong, China, start from 2011,sell to Southeast Asia(20.00%),Africa(20.00%),Eastern Asia(10.00%),Mid East(10.00%),Domestic Market(5.00%),South Asia(5.00%),Northern Europe(5.00%),Central America(5.00%),Western Europe(5.00%),South America(5.00%),Eastern Europe(5.00%),North America(5.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
pressure regulator,Tube fittings,solenoid valve,Needle valve,check valve

4. why should you buy from us not from other suppliers?
We have a couple of years with professional engineers and dedicated technicians.can provide security products for you

5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,Western Union;
Language Spoken:English,Chinese
