Pinion gear and input shaft for ADVANCE MARINE GEARBOX 300 01 005 D300 01A 001 300 01 102A D300 01A 101B

Share on (1600669686752):


Price:$1,000.00

Quantity:


Product Overview

Description



Product Description




Specification


item
Gear and shaft for advance marine gearbox
Warranty
one year
Applicable Industries
Other
Weight (KG)
15
Place of Origin
China
Brand Name
ADVANCE
Gearing Arrangement
Spur
Output Torque
1000
Input Speed
2200
Output Speed
490
Pinion gear and shaft
300-01-005 D300-01A-001 300-01-102A D300-01A-101B


Packing & Delivery




ADVANCE MARINE GEARBOX 300 D300A Z300
bolt
300-01-026
bolt
M12*25GB21-76
lock washer
300-01-025
spring washer
12GB93-76
Plate
300-01-001A
Gasket
300-01-021
bolt
M14*50GB21-76
spring washer
14GB93-76
adjusting ring
300-01-002
adjusting ring
D300-01A-002
coupling bracket
300-01-003
coupling bracket
D300-01A-003A
bearing
176222 GB294-64
lock washer
105 GB858-76
nut
300-01-007
thrust ring
300-01-004
thrust ring
MB270-01-015
bearing
42222GB283-64
Pinion
300-01-005
pinion
D300-01A-001
bearing
2222 GB283-63
bearing spacer
30300-01-023
clutch housing
30300-01-006
clutch housing
D300-01A-004
spring washer
10GB93-73
socket head cap screw
M10*25GB70-76
input shaft
300-01-102A
input shaft
D300-01A-101B
Sealing
30001—0163
Plug
Q21-14
Plug
Q21-38
Plug
Q21-45
Clutch bracket
300-01-101
Thrust Plate
300-01-008
External disc
300-01-009A
Intemal disc
300-01-010
return spring
300-01-013A
piston
300-01-011A
gear
300-01-019B
bearing
42221GB283-81
piston ring
300-01-012
emergency pin
300-01-020
o-ring
300-01—014
o-ring
42*3.5 GB1235-76
Positioning plat
300-01-015
Safety pie
300-01-018
Bolt
M10*20GB21-76
bearing bush
D300-01A-005
plug
Q21-39
ring
300-01-022
spacer
110 GB894-76
o-ring
GB/T34521-2005


wooden box
