PLC Control Automatic Feeding and CNC Cutting Metal Band Saw Machine GS320
- Category: >>>
- Supplier: Zibo Jepps Trading Co. Ltd.
Share on (1600675018582):
Product Overview
Description
Product Description
Specification
Product features of GS320 CNC band sawing machine
1. Fully automatic CNC sawing machine, suitable for continuous cutting in batch production.
2. Using PLC control system, one group or several groups of data can be set for continuous cutting, and the repeated feeding accuracy is 0.2mm.
3. Color touch screen operation, man-machine interface replaces traditional button control panel.
4. Adopting grating ruler to control the feeding length, the single largest feeding stroke is 500mm, and the length of more than 500mm can be divided into multiple feedings.
1. Fully automatic CNC sawing machine, suitable for continuous cutting in batch production.
2. Using PLC control system, one group or several groups of data can be set for continuous cutting, and the repeated feeding accuracy is 0.2mm.
3. Color touch screen operation, man-machine interface replaces traditional button control panel.
4. Adopting grating ruler to control the feeding length, the single largest feeding stroke is 500mm, and the length of more than 500mm can be divided into multiple feedings.
GS320 | ||
最大锯切能力 Maximum sawing capacity | Ф320mm □320x320mm | |
最小锯切能力 Minimum sawing capacity | Ф0mm □0x0mm | |
成束锯切 Bundle sawing | maximum280W×140H The smallest200W×90H | |
主电机功率 main motor power | 3.0kw | |
液压电机功率 Hydraulic motor power | 0.75kw | |
水泵电机功率 Water pump motor power | 0.09kw | |
锯带速度 Band speed | 40/60/80m/min | |
锯带规格 Saw band specification | 4115*34*1.1 | |
锯带张紧方式 Saw band tensioning method | manual | |
机床外形尺寸(L×W×H) Machine size | 1900mm×1600mm×1500mm | |
机床净重 Machine weight | 1400kg | |
毛重 Gross weight | 1680KG | |
