Material | 304 stainless steel externally,316L stainless steel internally |
Clean Grade | CLASS A |
Leakage rate | ≤0.5%VOL/h (under 100Pa) |
Air change | ≧80T/h |
Vaporization temperature | ≤60℃ |
Compressed air | ≥0.5Mpa |
Sterilizer | better than 30% food grade hydrogen peroxide solution |
VHP residue removal efficiency | ≤1PPM |
Control method | manual or automatic |
Noise | ≤70dB(A) |
Specification/model | Outer size W*D*H, unit: mm | Inner dimension w*d*h unit: mm | Exhaust connection | Fresh air outlet | power supply | Maximum power consumption KW |
VHPB-125 | 950*600*1800 | 500*500*500 | DN50 | DN150 | AC220v/50Hz | 3.5 |
VHPB-200 | 1050*700*1900 | 600*600*600 | DN50 | DN150 | 3.5 | |
VHPB-350 | 1150*800*2000 | 700*700*700 | DN50 | DN200 | 3.5 | |
VHPB-500 | 1250*900*2100 | 800*800*800 | DN75 | DN200 | AC380V/50Hz | 5.5 |
VHPB-800 | 1350*1000*2200 | 900*900*1000 | DN75 | DN250 | 5.5 | |
VHPB-1000 | 1450*1100*2300 | 1000*1000*1000 | DN75 | DN250 | 5.5 | |
VHPB-1200 | 1650*1100*2300 | 1200*1000*1000 | DN75 | DN250 | 5.5 |
