Lightweight 60mm XPS Sandwich Panel Core for RV Insulation Wall
- Category: XPS Boards >>>
- Supplier: Shanghai,Topolo,New,Materials,Co.,Ltd.
Share on:
Product Overview
Description
XPS foam is an insulating panel manufactured with fully recyclable material. It is produced from extruded polystyrene, a material that doesn’t deteriorate. The foam structure is constructed with very fine closed cells that provide excellent physical and mechanical characteristics.
* Heat Insulation Performance
XPS foam doesn’t conduct heat due to the special cell structure. When XPS panels are laid as a wall liner or floor underlay, any heat from the room or truck body will be reflected back towards the surface. This helps to prevent heat wastage, and thereby, lowers your energy consumption and carbon footprint.
* Damp Protection
XPS foamed products are also water repellent. They never rot or support mold growth and help hold back any dampness from the structure. XPS panels are also resistant to cement, plaster, and most alkalis except organic solvents.
* Soundproof
In addition, XPS foam has excellent sound insulating properties, which makes your truck or room floor “quieter” to walk on. It is an ideal product that reduces sound transmission to the level below.
Specification
Width | Max 3.2m |
Thickness | 25mm~120mm |
Length | Custom-made |
Core Density | 35kg/m3~45kg/m3 |
Color | White, black, green, yellow, or customized. |
Application | RVs, trailers, vans, refrigerated trucks, campers, Caravans, motorboats, mobile homes, clean rooms, cold rooms, etc. |
Technical Parameters of XPS Thermal Insulation Foam
Density | Kg/m3 | 32~43 |
Thermal conductivity, 90 days, 10℃ | W/mK | 0.027~0.03 |
Compressive strength at 10% deflection or yields, (vertical) | KPa | ≥300 |
Tensile strength | KPa | ≥300 |
Water absorption | Vol-% | ≤1.00% |
Capillarity | nil | nil |
Coefficients of linear thermal expansion | mm/mK | 0.07 |
Temperature limits | ℃ | -50℃~70℃ |
XPS Foam Can Be Composited With Different Materials
FRP sheet + XPS foam
Aluminum Sheet + XPS foam
Wood Board + XPS foam
Application
XPS foam board is mainly used in thermal insulation, such as RV bodies, refrigerated truck bodies, cold rooms, building wall panels, etc.
Processing of XPS Foam Board in TOPOLO
Professional International Sales Team
Professional international sales team – English, French, Russian, Spanish, Portuguese, etc., make our communication unimpeded, from pre-sales product consultation to after-sales logistics services, to provide you with professional solutions.
