High-efficiency stretching machine - Screen Mesh Stretcher
Henan Yuanzhen machinery designed automatic taut screen machine, also known as pneumatic aluminum double-clamp pulling machine, combined with the advantages of domestic and foreign taut screen machine, compact structure, high tension taut screen, easy to operate and use, good appearance, is the ideal machine for making vibrating screen, advertising and other large screen plates and professional batch plate making.
Structural principle
1. one end of the mesh (length direction) evenly clamped, and then pulled flat clamped on both sides, and then the remaining part of the folded clamping. In order to ensure the quality of taut mesh, clip the cloth as flat as possible, between the net clamps one by one tightly, leaving no gaps.
2. clip good net cloth, the hand wheel on the taut network frame clockwise rotation, at this time the hand wheel (screw) drive turbo, gears, rack drive, move outward, taut net cloth, and vice versa when the counterclockwise rotation of the hand wheel for loosening the net cloth. Tension can be pulled on all sides at the same time, can also be pulled separately and progressively, the length of the direction due to the extension ratio is different, relatively longer than the two sides should be drawn some.
3. when the taut force to achieve the required requirements, then the cylinder operating board manual valve to the left, so that the whole pallet parallel to rise, so that the net frame close to the net, can be coated with dip net glue. After staining the screen cloth steadily, when the glue is dry, you can remove the screen plate. Then swing the manual valve in the opposite direction, and the whole pallet will be lowered into position.
2. clip good net cloth, the hand wheel on the taut network frame clockwise rotation, at this time the hand wheel (screw) drive turbo, gears, rack drive, move outward, taut net cloth, and vice versa when the counterclockwise rotation of the hand wheel for loosening the net cloth. Tension can be pulled on all sides at the same time, can also be pulled separately and progressively, the length of the direction due to the extension ratio is different, relatively longer than the two sides should be drawn some.
3. when the taut force to achieve the required requirements, then the cylinder operating board manual valve to the left, so that the whole pallet parallel to rise, so that the net frame close to the net, can be coated with dip net glue. After staining the screen cloth steadily, when the glue is dry, you can remove the screen plate. Then swing the manual valve in the opposite direction, and the whole pallet will be lowered into position.
1. the use of adjustable pressure aluminum double chuck, pulling high tension will not retreat from the net, the body baking paint, wear-resistant and scratch-resistant, not easy to change color, the cylinder top net clamp mouth using stainless steel, connected to the air nozzle connector using stainless steel installation.
2. the use of sprockets, chains, wire rod drive, so that the taut network synchronization. With more than one cylinder synchronization to ascend the net to ensure that the net, the net pattern is not deformed, easy to stick the net.
3. according to the width of the mesh and the size of the mesh frame to change the size of the taut frame, contraction, expansion of the size of the taut frame operation, positioning is convenient. Small frame can be taut more than one time.
4. both with chain tensioning mechanism. Guide column guidance, positioning, to ensure parallel displacement of the taut net, to prevent mechanical deformation, to protect the wire rod.
2. the use of sprockets, chains, wire rod drive, so that the taut network synchronization. With more than one cylinder synchronization to ascend the net to ensure that the net, the net pattern is not deformed, easy to stick the net.
3. according to the width of the mesh and the size of the mesh frame to change the size of the taut frame, contraction, expansion of the size of the taut frame operation, positioning is convenient. Small frame can be taut more than one time.
4. both with chain tensioning mechanism. Guide column guidance, positioning, to ensure parallel displacement of the taut net, to prevent mechanical deformation, to protect the wire rod.
Common Model
Type | Model | Max stretch size (mm) | Min stretch size(mm) | Maximum tension of taut mesh(N/cm2) | ||||
single track - ordinary type | YZ-120 | 1200*1500 | 600*600 | 40 | ||||
YZ-150 | 1500*1500 | 600*800 | ||||||
YZ-200 | 1500*2000 | 600*1000 | ||||||
single track - turbo worm type | YZ-120 | 1200*1500 | 600*600 | |||||
YZ-150 | 1500*1500 | 600*800 | ||||||
YZ-200 | 1500*2000 | 600*1000 | ||||||
double track - ordinary type | YZ-120 | 1200*1500 | 600*600 | |||||
YZ-150 | 1500*1500 | 600*800 | ||||||
YZ-200 | 1500*2000 | 600*1000 | ||||||
double track - electric type | YZ-120 | 1200*1500 | 600*600 | |||||
YZ-150 | 1500*1500 | 600*800 | ||||||
YZ-200 | 1500*2000 | 600*1000 | ||||||
Support customized production（Click here to get accurate quotation） | ||||||||
Power | Customize |
Customization | Customized logo(Min. Order: 50 Pieces) Customized packaging(Min. Order: 50 Pieces) Graphic customization(Min. Order: 50 Pieces) |
Shipping | Support Express · Sea freight · Land freight · Air freight |
Support | 1 Year for machinery warranty 1 Year for Core Components |
Protection | Trade Assuranceprotection your alibaba.com order On-time Dispatch GuaranteeRefund Policy |
application | Used with a vibrating screen, mainly used for the work of stretching the screen and changing the screen |
certification | SGS |
Machinery Test Report | Provided |
Video outgoing-inspection | Provided |
Marketing Type | New Product 2021 |
Voltage | 220V |
Motor | Ordinary motor |
Surface treatment | none |
Function | Tighten the screen mesh and change the screen mesh |
Advantage | Fast screen change, even tension, easy to operate |
