Stainless Steel Water Flow Switch Air Flow Sensor AC220V Power Supply Fire Fighting Flow Switches
Product Description
Product brief introduction
Thermal flow switch is based on the principle of heat exchange design, probe the built-in heating module as well as the thermal module, heat dissipation of heating module and the flow velocity is closely related to the body. If there is no medium flow in the pipe ,thermal circuit receives a fixed value, when the fluid flows through the probe, thermal circuit receives the signal changes over medium velocity, thermal circuit will convert the temperature difference signals of heating module and thermal module into electrical signals, the processor will convert it into PNP/ NPN/ relay signal output.
Feature
LED indicate the velocity
No movable parts, free maintenance
Various length of sensors can be chose
Easy installation
One type for various pipe diameter
Continuously adjustable switch value
Almost no pressure loss
Overall protection grade IP67
Water flow sensor technical parameter
| Measure range | Water:3~300cm/s ; Air:200~300cm/s ; Oil:3~300cm/s |
| Accuracy | ±1~±10cm/s |
| Settling time | 3 minutes |
| Pressure | 100Bar |
| Media temperature | -20 to 80℃ |
| Thread | G1/2 ,G1/4 Male thread /M18 Female thread |
| Output signal | PNP / NPN / Relay |
| Power | 24VDC , 110VAC , 220VAC |
| Sensor length | 15mm , 20mm , 30mm , 40mm , 60mm |
| Consumption current | <60mA |
| Setting | Potentiometer |
| Response time | 2(2-10)s |
| Max.temperature gradient of medium | 300K/min |
| Protect | Reverse / Short / Overload |
| Protection grade | Ip67 |
| Power connector | M12 connector |
| Material | Sensor : 316L Body : 316L |
| Load | Current : 250mA Relay : 30VDC/5A ,110VAC/5A, 220VAC/5A |
Detailed Images
Related Products
Company Information
Certifications
Application
Gas liquid dual use ,it can be used for gas and hydraulic pressure system, circulating water, monitoring of the cutting fluid and lubricant, as well as Idling of pump protection,iron and steel ,metallurgy ,pharmaceutical ,chemical industry, etc.
FAQ
Q: Are you the final manufacturer?
A: Yes, We are manufacturer
Q: Do you offer the OEM order ?
A: Yes, we can offer OEM service and label according to your requirements
Q: How to make payment?
A: We accept T/T , Credit card
Q: Could we visit your factory?
A: Yes, Sincerely invite you to visit our factory
Q:Do you have any discount?
A:Yes, if you buy large quantity, please contact us or send email, we will give you a big discount
Q: What is your delivery time?
A: It is about 5-7 working days since the payment confirmed . If the quantity more than 100pcs , it will need extra 3-5 working days
Q: How long is the warranty of your products ?
A: 2 years warranty
