SKE manufacturer MPPT solar PV charger inverter solar power system 5kva inverter for electronic product
- Category: >>>
- Supplier: Shenzhen Smartkey Power Co. Ltd.
Share on (1600687916261):
Product Overview
Description
MODEL | PH21-1.2K | PH21-3.6K | PH21-6.2K | |||||
RATED POWER | 1200VA/1200W | 3600VA/3600W | 6200VA/6200W | |||||
INPUT | ||||||||
Voltage | 230 VAC | |||||||
Selectable Voltage Range | 170-280VAC(For Personal Computers)； 90-280VAC(For Home Appliances) | |||||||
Frequency Range | 50 Hz/60 Hz (Auto sensing) | |||||||
OUTPUT | ||||||||
AC Voltage Regulation (Batt. Mode) | 230VAC±5% | |||||||
Peak Power | 2400VA | 7200VA | 12400VA | |||||
Eficiency(Peak) | 93% | |||||||
Transfer Time | 10 ms(For Personal Computers); 20 ms(For Home Appliances) | |||||||
Wavefom | Pure sine wave | |||||||
BATTERY | ||||||||
Battery Voltage | 12 VDC | 24 VDC | 48 VDC | |||||
Floating Charge Voltage | 13.5 VDC | 27 VDC | 54 VDC | |||||
Overcharge Protecion | 14.6 VDC | 329.2 VDC | 58.4 VDC | |||||
SOLAR CHARGER & AC CHARGER | ||||||||
Solar Charger type | MPPT | MPPT | MPPT | |||||
Maximum PV Array Open Circuit Voltage | 450 VDC | 500 VDC | 500 VDC | |||||
Maximum PV Array Power | 2000 W | 4000 W | 6000 W | |||||
MPP Range Operating Voltage | 60～400VDC | 60~450 VDC | 60～450 VDC | |||||
Maximum Solar Charge Current | 60 A | 80 A | 80 A | |||||
Maximum AC Charge Current | 60A | 80A | 80 A | |||||
Maximum Charge Current | 60 A | 80 A | 80 A | |||||
ENVIRONMENT | ||||||||
Humidity | 5% to 95% Relative Humidity(Non-condensing) | |||||||
Operating Temperature | 0℃ to 50℃ | |||||||
Storage Temperature | -15℃ to 60℃ | |||||||
MODEL | PH21-1.2K | PH21-3.6K | PH21-6.2K | ||||
RATED POWER | 1200VA/1200W | 300VA/3600W | 6200VA/6200W | ||||
Dimension DxWxH(mm) | 354x261x399 | 334x 309x109 | 440×309×109 | ||||
Net Weight (kg) | 5.7 | 8.3 | 9.6 | ||||
Communication Interface | USB/RS232 | ||||||
