56.4v battery charger 48v 20a charger with US input and heavy duty alligator clips output 1000W 1300W NMC battery in 13S
56.4v battery charger 48v 20a charger with US input and heavy duty alligator clips output 1000W 1300W NMC battery in 13S
56.4v battery charger 48v 20a charger with US input and heavy duty alligator clips output 1000W 1300W NMC battery in 13S
56.4v battery charger 48v 20a charger with US input and heavy duty alligator clips output 1000W 1300W NMC battery in 13S
56.4v battery charger 48v 20a charger with US input and heavy duty alligator clips output 1000W 1300W NMC battery in 13S
56.4v battery charger 48v 20a charger with US input and heavy duty alligator clips output 1000W 1300W NMC battery in 13S
56.4v battery charger 48v 20a charger with US input and heavy duty alligator clips output 1000W 1300W NMC battery in 13S
56.4v battery charger 48v 20a charger with US input and heavy duty alligator clips output 1000W 1300W NMC battery in 13S

56.4v battery charger 48v 20a charger with US input and heavy duty alligator clips output 1000W 1300W NMC battery in 13S

Share on (1600688017690):


Price:$95.00 - $123.00

Quantity:


Product Overview

Description



Technical Specification


48v 56.4v 20a battery charger with us input and heavy duty alligator clips output
1000w 1300w battery chargers
All in one Intelligent Solar Street light control system 12v Charge FIve-time periods control with Infrared or Microwave.
5a 8a 10a all in one solar street light controllers
Depower 12V/24V 10A/20A MPPT Solar Charge Controller with RS485/BT LCD display for solar system
10a 20a mppt controllers


On Board Charger Specification


Battery type
LiFePO4 in 15 Series/LiFePO4 in 16 Series/NMC in 13 series
Model name
PBCD-1000-540-20
PBCD-1300-540-25
PBCD-1600-540-30
PBCD-1000-576-20
PBCD-1300-576-25
PBCD-1600-576-30
PBCD-1000-546-20
PBCD-1300-546-25
PBCD-1600-546-30
Input
Voltage range
90～264VAC
Frequency range
45～65Hz
Input current(Typ.)
5A
6.5A
8A
Max. Efficiency(Typ.)
94%
Leakage current
<0.5mA/220VAC (60335-1/2-29), 1.5mA Peak/240VAC (62368-1)
Output
Charging phase
Pre-charge + constant current + constant voltage
Max. output power
1000W@220VAC 500W@110VAC
1300@220VAC 650W@110VAC
1600W@220VAC 800W@110VAC
Max. output current
20A@220VAC 10A@110VAC
25A@220VAC 12.5A@110VAC
30A@220VAC 15A@110VAC
Constant voltage
54.0V(LiFePO4 in 15 Series)/ 57.6V(LiFePO4 in 16 Series)/ 54.6V(NMC in 13 series)
Protection
Short circuit
Yes
Over temperature
Yes
Environment
Waterproof
IP65
Working Temp.
–20～50℃
SAFETY & EMC
Safety standards
EN60335, GB/T4706
Isolation resistance
I/P-O/P, I/P-FG, O/P-FG: 100M ohms/500VDC/25℃/70%RH
EMC emission
EN55022 Class A, GB/T 9254 Class A


Product Feature- OBCD Series battery charger 54.0V/ 57.6V/ 54.6V
1. Use internationally well-known semiconductor devices,such as IR, TI, ST, ON and so on
2.  Charging conversion efficiency is up to 94%
3. Support lithium and lead-acid battery
4. Short circuit/ Over voltage/ Over temperature protection


Battery charger 20A
