Product Overview
Description
Product Description
Using international beer standard fermentation production technology, real-time detection of online data, remote monitoring technology can be realized, and the mirror polishing inside the tank can reach the polishing quality standard of 0.2~0.4μm, which fully meets the automatic cleaning of the programmable controller Automatic control requirements for disinfection systems.
The cooling jacket of the fermentation tank also conforms to the technical standards of various countries in the world. It provides a variety of jacket heat exchange methods, such as Maitreya plate, arch channel, tile channel and so on. Meet the technical requirements of heat exchange for different cooling media and pressures.
The cooling jacket of the fermentation tank also conforms to the technical standards of various countries in the world. It provides a variety of jacket heat exchange methods, such as Maitreya plate, arch channel, tile channel and so on. Meet the technical requirements of heat exchange for different cooling media and pressures.
Features
1. Made by 304/316L SS, TIG welded
2. Design comply with requirements of GB/PED/ASME
3. Polished to 0.4 microns,360 degree cleaning without deadcorner
4. 60 degrees cone design, suitable for yeast discharge
5. Rotary beer racking arm with horizontal design for less lose
6. Cooling jacket on side wall and cone,auto temp control
7. Pressure adjustable for pressured and non-pressured fermentation
8. Allow dry hopping for IPA and other beer
2. Design comply with requirements of GB/PED/ASME
3. Polished to 0.4 microns,360 degree cleaning without deadcorner
4. 60 degrees cone design, suitable for yeast discharge
5. Rotary beer racking arm with horizontal design for less lose
6. Cooling jacket on side wall and cone,auto temp control
7. Pressure adjustable for pressured and non-pressured fermentation
8. Allow dry hopping for IPA and other beer
Product Parameters
1 | Total capacity | 1000L+25% | 16 | Inner Polishing | 0.2-0.4micron |
2 | Effective capacity | 1000L | 17 | Working pressure | 2 bar |
3 | Material | SUS304 | 18 | Cooling type | Dimple cooling jacket |
4 | Exterior shell | 2mm | 19 | Cooling area | Included |
5 | Interior shell | 3mm | 20 | Cooling jacket inlet | G3/4 |
6 | Insulation material | PU | 21 | Cooling jacket outlet | G3/4 |
7 | Insulation TH | 80mm | 22 | Pressure control | Spunding valve |
8 | Top type | Dished head | 23 | Pressure gauge | 1pc |
9 | Manhole Type | Included | 24 | Rotating Racking arm | Φ51 |
10 | Manhole size | Φ350 | 25 | Sample port | Φ32 |
11 | Inner cone | 60 degree | 26 | Drain outlet | Φ38 |
12 | CIP pipe Diameter | Φ32 | 27 | Safety valve (PVRV) | Φ51 |
13 | CIP ball(1) | 360º Rotating spray ball | 28 | Balance port | Φ32 |
14 | Temperature sense | PT100 sensor | 29 | Carbonation stone | Options |
15 | Thermowell diameter | Φ10 | 30 | Support leg | 4*SUS 304 |
31 | Adjustable bolt | 4pcs |
