Hot sale AlwayLink wireless Wifi 6 AX3000 RM520N GL Modem ipq5018 5g sim card router
- Category: Routers >>>
- Supplier: Shi,Di,Fen,(Shenzhen),Technology,Co.,Ltd.
Share on:
Product Overview
Description
Hot sale AlwayLink wireless Wifi 6 AX3000 RM520N-GL Modem ipq5018 5g sim card router
5G & WiFi-6 Smart Router System(CPE)
Summary
5G & WiFi-6 Smart Router System (CPE), is based on a brand-new embed platform, it can be satisfied with growing-up mobile
connections requirements and provides a fast speed beyond your imagination.
The CPE is compatible with NSA/SA dual-mode, and suits to all network types all over the world, it means you just plug and play it and
enjoy ultra-fast broadband connection at any place.
The CPE brings a new way to enable you to experience VR/AR/4K/8K streaming freely and easily. With 802.11ax (Wi-Fi 6) technology
built-in, the single CPE has wider wireless coverage and more bandwidth. Meanwhile, the CPE brings higher security, better network
efficiency, and longer battery life.
Key Features
n 5G NR Cellular
Qualcomm™SDX62 modem
n Wi-Fi 6 (802.11ax) AX3000
Support 160M bandwidth
n 2.5G WAN Port
2.5G Port
n MESH Networking
Support MESH networking
Datasheet
CPU | IPQ5018+SDX62 |
WiFi Frequency | 2.4G&5G |
WiFi Standard | 2.4G:802.11b/g/n /ax 2T2R MIMO, 5.8GHz:802.11a/n/ac/ax 2T2R MIMO |
| WiFi | 2.4GHz :600Mbps ,5GHz :2400Mbps |
| 5G NR | 3GPP Release 16 NSA/SA operation, Sub-6 GHz |
| 5G Network Mode | NSA/SA |
| 5G/4G Data Rate | 5G SA Transmission Speed:2.1Gbps/900Mbps (up to ISPs) 5G NSA Transmission Speed:2.5Gbps/650Mbps (up to ISPs) LTE : Down 1.0 Gbps;UP 200 Mbps |
| 5G Frequency Bands | 5G NR NSA n1/ 2/ 3/ 5/ 7/ 8/ 12/ 13/ 14/ 18/ 20/ 25/ 26/ 28/ 29/ 30/ 38/ 40/ 41/ 48/ 66/ 70/ 71/ 75/ 76/ 77/ 78/ 79 5G NR SA n1/ 2/ 3/ 5/ 7/ 8/ 12/ 13/ 14/ 18/ 20/ 25/ 26/ 28/ 29/ 30/ 38/ 40/ 41/ 48/ 66/ 70/ 71/ 75/ 76/ 77/ 78/ 79 MIMO Downlink:4 × 4 MIMO on n1/n2/n3/n7/n25/n38/n40/n41/n48/n66/n77/n78/n79 |
| 4G&3G Frequency Bands | Downlink Cat 19/ Uplink Cat 18 LTE-FDD B1/ 2/ 3/ 4/ 5/ 7/ 8/ 12/ 13/ 14/ 17/ 18/ 19/ 20/ 25/ 26/ 28/ 29/ 30/ 32/ 66/ 71 LTE-TDD B34/ 38/ 39/ 40/ 41/ 42/ 43/ 48 MIMO DL: 4 × 4 MIMO on B2/B4/B5/B12/B13/B14/B17/B25/B26/ B29/B30/B66/B41/B42/B43/B48/B71 WCDMA B1/ 2/ 4/ 5/ 8/ 19 |
| Modulation Mode | 5G: GMSK/8PSK/BPSK/QPSK/16QAM/64QAM/256QAM WIFI: 1024-QAM / OFDMA |
Dimension | 108X108X216MM |
Interface | 2*10/100M/1000 LAN 1*10/100M/1000/2500 WAN 1*12V 2A DC Power Input 1 Reset Button 1 SIM card slot(4FF SIM card Support SIM/USIM/UIM, standard 6 PIN SIM card interface, support 3V SIM card and 1.8V SIM card: internal) 1 Breathing Light Button |
Network Extension | MESH |
Reset | Reset( Long press 10 seconds to restore the factory settings) |
| MESH | Networking: short press (blue networking light flashes) |
| LED Indicator | Power, Breathing Light, 4G Signal, 5G Signal, WiFi Signal |
| Power Consumption | <24W |
| Environment | Operating Temperature:-20℃~+50℃ Storage Temperature:-40℃~+70℃ Humidity:5%~95%(Non condensation) |
Weight | 1.8KG( Includes color box accessories) |
What’s in the package?
• One (1) 5G CPE Router (AL01K21)
• One (1) 1m Cat6 Ethernet cable
• One (1) Power Adapter
• Quick Start Guide
5G Module Optional:
5G Modem | |
Cat16 /Cat20 Optional
| |
5G &4G Feture | 5G &4G Feture: 5G NR:3GPP Release 16 NSA/SA operation, Sub-6 GHz 5G NR NSA : n1/n2/n3/n5/n7/n8/n12/n13/n14/n20/n25/n26/n28/n29/n30/n38/n40/n41/n48/n66/n71/n75/n76/n77/n78/n79 5G NR SA: n1/n2/n3/n5/n7/n8/n12/n13/n14/n20/n25/n26/n28/n29/n30/n38/n40/n41/n48/n66/n71/n75/n76/n77/n78/n79 LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29/B30/B32/B66/B71 LTE-TDD: B34/B38/B39/B40/B41/B42/B43/B48 WCDMA B1/B2/B4/B5/B8/B19 |
