Vlais Cummins 40kva 32kw 3 фазы дизельный генератор с двигателем Cummins альтернатором stamford

Vlais Cummins 40kva 32kw 3 фазы дизельный генератор с двигателем Cummins альтернатором stamford

Price:6 500,00 $ - 6 700,00 $

Price in USD:Details

Quantity:

Product Description

Diesel Generator Data Sheet
Generator Model	CP-C40
Rated Power	32KW/40KVA
Rated Voltage	110V/220V/380V(Customization available)
Frequency	50HZ/60HZ
Power Factor	COS=0.8
Weight(kg)	950KG
Cooling Method	Water-cooled
Start-up Mode	DC 18V/Electric Start
Diesel Engine Data Sheet
Brand	Cummins
Model	4BT3.9-G2
Number of Cylinder	4 Cylinder Vertical in Line
Speed	1500RPM(50hz)/1800RPM(60hz)
Cycle	4 Stroke
Asp.	Turbo charged
Cooling Method	Water-cooling
Bore*Stroke(mm)	102*120
Compression Ratio	17.3:1
Speed Governor	Electronic
Fuel Consumption	0.23L/kw h
Fuel Tank	8-10 Running Time
Alternator Data Sheet
Brand	Stamford/ Marathon/ Leroysomer
Model	CP-184J
Connecting Type	Single Phase/Three Phase and Four Wires
Number of Bearing	Single
Protection Grade	IP23
Insulation Class	H
Exciter Type	Brushless, Self-excited, AVR Controller
Altitude	≤1000m
Controller
Optional Controller Brand	Deepsea / ComAp / Smartgen
