The same size big front tires and rear tires Backhoe Loader 4x4 driving for sale
- Category: >>>
- Supplier: Sinoway Industrial (Shanghai) Co. Ltd.
Share on (1600694251608):
Product Overview
Description
Product Show
Specification
ENGINE | |
Emission Regulation | Tier 3 / Stage IIIA |
Make | Perkins |
Model | 1104D - 44TA |
Gross Power | 74.5 kW (100 hp / 101 ps) @ 2,200 rpm |
Net Power | 72 kW (97 hp / 98 ps) @ 2,200 rpm |
Peak Torque | 410 N•m @ 1,400 rpm |
Displacement | 4.4 L |
DRIVE TRAIN | |
Number of Drive Wheels | 4 WD |
1st Maximum Speed | 6.6 km/h |
2nd Maximum Speed | 10.8 km/h |
3rd Maximum Speed | 24 km/h |
4th Maximum Speed | 41 km/h |
OutsideTurning Radius, Front Tire | 4,850 mm |
OutsideTurning Radius, Bucket | 5,200 mm |
TIRES | |
Front Tire Size | 16.9-28 12RP TL |
Rear Tire Size | 16.9-28 12RP TL |
LOADER PERFORMANCE | |
Bucket Capacity | 1.1 m3 |
Standard Bucket Width (referenced) | 2,440 mm |
Lift Capacity at Full Height | 30.2 kN |
Bucket Breakout Force | 59.6 kN |
Maximum Dump Angle at Full Height | 45° |
Dump Height at Maximum Angle | 2,746 mm |
Dump Reach at Full Height Discharge | 570 mm |
Boom Lift Capacity, end, at ground | 47.3 kN |
Maximum Dig Depth | 30 mm |
BACKHOE PERFORMANCE WITH STANDARD STICK | |
Standard Bucket Type (referenced) | 0.2 m3 |
Standard Bucket Heaped Capacity ISO(referenced) | 0.2 m3 |
Standard Bucket Width (referenced) | 610 mm |
Maximum Dig Depth | 4,345 mm |
Reach From Swing Pivot at Ground | 5,443mm |
Turning Angle of Bucket | 186° |
Bucket Digging Force | 58.2 kN |
Dipper Digging Force, standard stick | 37.5 kN |
Loading Height | 3,586 mm |
Loading Reach from Swing Pivot | 3,908 mm |
SERVICE CAPACITIES | |
Fuel Tank | 130 L |
Engine Oil | 8 L |
Cooling System | 16L |
Hydraulic Reservoir | 130 L |
Hydraulic System Total | 180 L |
Transmission and Torque Converter | 16 L |
Axle, front | 11.1 L |
Axle, rear | 12 L |
Operating Weight | 9,480 kg |
