CNTD Various Actuators Waterproof Oilproof IP67 Aluminum Cast Shell 10A 380V Vertical Limit Switch CZ 3107
- Category: >>>
- Supplier: Cntd Electric Technology Co. Ltd.
Share on (1600694455092):
Product Overview
Description
Features
High mechanical strength, mainly consists of aluminum cast
Water-proof, oil-proof and dust proof construction
Various actuators for different applications
Specifications
Rating | 5A 125V,3A 250VAC | ||||||
Operating speed | 1mm-1m/s (Swing rod type) | ||||||
Operation speed | 0.1mm-0.5m/s (Plunger type) | ||||||
Operating frequency | Electical: 30 operations/min | ||||||
Contact rsistance | 25mΩ max. (initial value) | ||||||
Insulation resistance | 100mΩ min. (below 500VDC) | ||||||
1000VAC, 50/60Hz for 1 minute between terminals of the same polarity | |||||||
1500VAC, 50/60 Hz for 1 minute between current-carrying and non-current-carrying metal parts | |||||||
1500VAC, 50/60 Hz for 1 minute between each terminal and ground | |||||||
Vibration | 10~55Hz,1.5mm double amplitude | ||||||
Shock | Mechanical:Approx 1,000m/s² (about 100G'S) Malfunction:Approx 500m/s² (about 50G'S) | ||||||
Ambient temperature | Using: -20~+70℃ (With no icing) | ||||||
Humidity | <95% RH | ||||||
Electrical life | 200,000 operations above | ||||||
Weight | Approx.360g(cable length 3m) Approx.540g(cable length 5m) | ||||||
Protection level | IP67 | ||||||
