8 Port PoE Ethernet 2 port Gigabit Uplink networking Switch Built in power supply AC110V/220V 270W POE switch
- Category: >>>
- Supplier: HiOSO Technology Co. Ltd.
Share on (1600695478148):
Product Overview
Description
Product Description
Customize 2 Gigabit Uplink 8 Port PoE Ethernet networking Switch POE switch
Character
l Support maximum 8 10/100/1000M RJ45 PoE ports and 2 1000M SFP uplink ports
l Each PoE port supports to auto discovery the standard power receiving device
l Support IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards
l Support 1000M port full rate, full-duplex non-blocking forwarding
l Support 16K MAC learning, 2Mbits storage and forward cache space,18G back plane bandwidth
l Each RJ45 port using anti-high voltage circuit, strengthen the lightning protection and anti-interference ability
l Support to choose one side with fixed metal casing, external power design, better for heat dissipating and installation
Technical Specification
Parameter | Specification |
Standard | IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX Fast Ethernet, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX Gigabit Ethernet, IEEE802.3af, IEEE802.3at, IEEE802.1d Spanning Tree |
PoE | PoE ports: 4 ports or 8 ports Standard and power consumption: IEEE802.3af 15.4W, IEEE802.3at 30W Working mode: auto discovery power receiving devices and auto power supply/power cutting |
Wavelength | SFP Module: 850nm/1310nm/1490nm/1550nm |
Distance | 100M SFP multi-mode: 2Km Single-mode: 20/40/60/80/100/120Km Single-fiber single-mode: 25/40/60/80/100/120Km 1000M SFP multi-mode:220m (fiber 62.5/125μm) / 550m (fiber 50/125μm) Single-mode:10/20/40/60/80/100/120Km Single-fiber single-mode: 10/20/40/60/80/100/120Km |
Port | 8 1000M RJ45 ports (PoE optional): 10/100/1000Mbps 2 1000M SFP ports: 1000M SFP |
MAC | 16K |
Buffer memory space | 2Mbit |
Bit error rate | <1/1000000000 |
MTBF | 100000 hours |
Power | DC48V(External power), AC110V/220V & DC48V redundant power back up(Internal power) |
Power consumption | 270W |
Working temperature | -10~60℃ |
Storage temperature | -40~80℃ |
Humidity | 5%~90% non-condensing |
Dimension | 28mm (H)×193mm(W)×119mm (D) |
