QSC 56 mini small 2000kg white rice cleaner accessory grain destoner for rice sheller machine african

Product Overview

Description

QSC 56 mini small 2000kg white rice cleaner accessory grain-destoner for rice sheller machine african

Product Usage

TQS series cleaning machine combines cleaning & destoning functions in one.So it can not only remove small and light impurities,but also stones. It is an ideal choice for small business.

This machine is mainly composed of cleaning screen box, stone removing screen box, transmission system and frame.



Product Structure

(1) With built-in fan,no need to add blower
(2) Compact structure, small land occupation.
(3) Stable operation and small noise.
(4) High cleaning efficiency and good effect

Working principle

The elevator transports rice to the hopper and enters the first layer of screen.Big impurities are discharged out of the machine from the big impurities outlet; The grains and small impurities enter the second layer of screen through the screen holes:Then the grains enter the stone removal screen and cleaned by the stone removal screen box. The clean grains are discharged from the grain outlet, and the stones are discharged from the stone outlet. Small impurities are discharged out of the machine from the other outlet.



Main Technical Parameters:

Model	Capacity	Power	Weight	Packing size
TQS-280	1 t/h	0.37KW	95kg	880*540*960mm
TQS-320	1-1.5 t/h	0.37KW	110kg	1080*600*1200mm
TQS-350	1.5-2 t/h	0.75kw	150kg	1090*690*1260mm
QSC-56	2-3 t/h	1.5kw	320kg	1150*890*1590mm
