homage ups inverter ups inverter 5000w 24 volt inverter pure sine wave
- Category: >>>
- Supplier: FOSHAN KOMISTAR ELECTRONIC CO. LTD
Share on (1600697533335):
Product Overview
Description
Products Details
Features：
Pure sine ware output
DC Start & Automatic Self-Diagnostic Function
High Efficiency Design & ”Power Saving Mode” to Conserve Energy
Auto restart when Ac in recovering
Smart battery charger design for optimized battery performance
Selectable charging current based on applications
Auto Restart Voltage
Model | HB-500 | HB-800 | HB-1000 | HB-1500 | |||||
Rated Capacity | 500VA | 800VA | 1000VA | 1500VA | |||||
Rated Power | 300W | 500W | 700W | 1050W | |||||
Transformer | Toroidal transformer | ||||||||
Interface | LED graphic | ||||||||
Display status | working&loading&battery | ||||||||
Working mode | PV(Photovoltaic priority)/AC(AC priority) optional | ||||||||
Input | Voltage | 140-275Vac | |||||||
Frequency | 45-65Hz | ||||||||
Output | Voltage | 220Vac±3% for inveter; 195v-240V for avr | |||||||
Frequency | 50/60Hz ± 0.3Hz, subject to the main | ||||||||
Wave Form | Pure sine wave | ||||||||
Wave Distortion | ≤3% | ||||||||
Protection | overload/high temperature/output high voltage /output low voltage/ battery low voltage shortcircuit/over-charge/over-discharge/reversed polarity(optional) | ||||||||
Transfer Time | ≤4ms | ||||||||
Battery Voltage | 12VDC | 12VDC | 12VDC | 24VDC | |||||
Charge Voltage | 13.6V±0.3V | 13.6V±0.3V | 13.6V±0.3V | 27.2V±0.6V | |||||
Low Battery Voltage Limit | 10.9V±0.3V | 10.9V±0.3V | 10.9V±0.3V | 21.8V±0.5V | |||||
Protections Battery Low Voltage Protection Point | 10.2V±0.3V | 10.2V±0.3V | 10.2V±0.3V | 20.5V+0.5V | |||||
Charge Current | Max.10A/15A/20A optional | ||||||||
Environmental | Operating Temperature | 0~40℃ | |||||||
Relative Humidity | 10%~90%RH,non-condensing | ||||||||
Storage Temperature | -15-45℃ | ||||||||
Packing | Machine Size(mm) | 230x145x180 | 337x146x170 | ||||||
Qty/Ctn | 4 | 4 | 2 | 2 | |||||
Carton Size(mm) | 785x305x240 | 415x410x245 | |||||||
CartonG.W.(kg) | 22 | 26 | 17.2 | 19.1 | |||||
Company Profile
Worldwide cooperation
Packaging
FAQ
Q1: Are you a manufacturer or a trading company?
We are a factory more than 20years experience to provide good quality with competitive price.
Q2:How about the delivery time?
Ready sample;7 working days for bulk order after your deposit is confirmed.
Q3: What kind of certification you have?
---ISO9001,ISO14001, CE,ROHS,UL,and so on ---All series UPS pass different labor testing according to different countries’ requirements.
Q4: Can I have a sample order?
---Yes, we welcome sample order to test and check quality.
Q5: Do you support OEM?
---Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
