System on Module Based on NXP i.MX 8M Mini CPU
Introduction:
SOM-iMX8MM is a commercial & industrial grade core board based on NXP i.MX 8M Mini CPU, and it comes with onboard 4GB RAM and 32GB eMMC. SOM-iMX8MM supports Android 10.0 operating system and a variety of interfaces like SPDIF, DSI, CSI, USB2.0 & USB OTG, GPIO, etc. For network connection, it supports WIFI-2.4Ghz/5Ghz, BT5.0 and 10Mbps/100Mbps/1000Mbps network port.
Main features:
• NXP i.MX 8M Mini CPU
• Android 10.0 operating system
• Onboard 4GB RAM, 2GB optional
• 32GB eMMC, 8GB/16GB/64GB/128GB optional
• 10Mbps/100Mbps/1000Mbps LAN, WIFI-2.4GHz/5GHz, BT5.0
Technical specification
System | |||||
CPU | MIMX8MM6CVTKZAA:Quad Cortex®-A53, 1.6GHz | ||||
(Support Consumer&Industrial i.MX 8M Mini SoloLite/Solo/DualLite/Dual/QuadLite/Quad) | |||||
Memory | Onboard 4GB LPDDR 4, Support2GB | ||||
Flash | 32GB eMMC5.1, Support 8GB/16GB/64GB/128GB | ||||
OS | Android 10.0, Ubuntu 18.04 server, Yocto 2.5.2 | ||||
Communication | |||||
WIFI & BT | WIFI-2.4GHz/5GHz, BT4.0 | ||||
LAN | 1 x 10/100/1000M LAN Port | ||||
Connectivity | |||||
SDIO | 1 x SDIO | ||||
CSI | 1 x CSI | ||||
DSI | 1 x DSI | ||||
PCIe | 1 x PCIe | ||||
USB | 1 x USB2.0 , 1 x USB OTG | ||||
SPI | 2 x SPI | ||||
QSPI | 1 x QSPI | ||||
I2C | 4 x I2C | ||||
UART | 3 x UART | ||||
JTAG | 1 x JTAG | ||||
I2S | 1 x I2S | ||||
SAI | 1 x SAI , 8 Channel | ||||
GPIO | 16 x GPIO | ||||
SPDIF | 1 x SPDIF | ||||
Physical interface | MXM3.0(Standard 314Pin) | ||||
Power | |||||
Power In | 5VDC/2A | ||||
Mechanical | |||||
Size | 82 x 50 x 1.2mm | ||||
