PTFE PEF MT Heat shrinkable Tube Customized instruments stomuc wash tube suction medical laboratory tubes

FEP heat shrink tubing has similar dielectric and frictional properties to PTFE heat shrink tubing. Except the Continuous operating temperature, FEP heat shrinkable tubing is suitable for continuous use at temperatures up to 200°C. But the begin shrink temperature of FEP tubing is just 130 °C, much lower than PTFE’s. This can be a significant advantage when used in conjunction with temperature sensitive components. The other advantage of FEP heat shrink tubing is that the max diameter of FEP heat shrink tubing we can produce is 215mm ID, much larger than PTFE’s.

Features and Benefits:
1. Excellent insulation
2. Operating temperature -180°C ~ 200 °C
3. No burn in the air (Oxygen Index>95vol%)
4. Excellent corrosion resistance
5. Low Friction: Dynamic friction coefficient 0.2-0.3

6. UV resistance

7. Large diameter up to 215mm.

8. Customize ( diameter, wall thickness, and color)

9. Shrink ratio:  1.3:1

10.  Lower shrink temperature 130 degree C to start shrink

11. Low pass for 5G using

 we can make 0.15 -0.25mm wall thickness, often  wall thickness is 0.15mm

also we can make the length as you need, like 850mm, 290mm,  500mm per pieces
