Новый тип 200kW Дизельная генераторная установка 250kVA питание дизель генератор 3 фазы 250 кВА генератор weichai дизельный 250 кВА
- Category: >>>
- Supplier: Jiangsu Haut Mechanical Co. Ltd.
Share on (1600699136005):
Product Overview
Description
Technical Parameters
| Diesel Generator Technical Data | |||
| Genset | HT-200 | Prime Power (KW) | 200 |
| Rated frequency(Hz) | 50/60 | Prime Power (KVA) | 250 |
| Rated speed(Rpm) | 1500/1800 | Phase | 3 Phase |
| Voltage | 220/380V,230/400V, 240/415V,120/240V | N.W (KG) | 2300 |
| Rated Current | 360A | Size (L*W*H) mm | 2850*1040*1200 |
| Diesel Engine Technical Data | |||
| Brand/Original | Weichai Power | Type | Water Cool, Electric start |
| Engine Item No. | WP10D238E200 | Cylinder No. | 6 |
| Displacement (L) | 9.7 | Bore and Stoke (MM) | 126*130 |
| Prime Power (KW) | 216 | Fuel Consumption | 195(g/kw.h) |
| Standby power (KW) | 238 | Combustion | Direct Injection |
| Governor | Electronic | Aspiration Type | Turbocharged |
| Alternator Technical Data | |||
| Brand/ Original | Stamford copy/ Stamford original/Marathon/Leroy-Somer | ||
| Alternator Model | HT-200D | Protection | IP23 |
| Alternator Type | Brushless sel-excited | Insulation | Class H |
| Phase / wire | 3-phase& 4 line | Factor | 0.8 |
Control Module Specifications | |||
| Digital Control Module suitable for a wide variety of single, diesel or gas, gen-set applications. Monitoring an extensive number of engine parameters, the module will display warnings, shutdown and engine status information on the back-lit LCD screen and illuminated LEDs. | |||
| The control module gives digital readouts of: | |||
| Generator voltage | Output frequency | Engine hours run | |
| Engine speed | Battery voltage | ||
| The control module has indicators for failure information: | |||
| High water temperature | Failure to start | Battery charger failure | |
| Automatic shutdown occurs under: | |||
| Low engine oil pressure | High engine water temperature | ||
| Over speed/Low speed | Failure to start after three attempts | ||
Optional
Soundproof/Silent/Mobile trailer Box:
1. Silent box: Acid pickling and phosphating treatment, anti-rust, anti-corrosion
2. Noise Level@7m: 72dB(A)
3. Color optional
4. Oil tank mounted on base frame for 8-12 Hours working
5. Excellent ventilation
6. Security and Safety
Our Advantages:
1. Solve technical problems and provide international warranty service for the engine within 24 hours
2. Design customized products according to customer requirements
3. Polyester varnish, anti-corrosion, protect the appearance and prevent rain
4. Test for two hours before delivery
5. ISO9001 and CE certification, strictly guarantee the quality
Delivery standard configuration:
1. Generator Set Distributor Random Technical Documents
2. Diesel engine, radiator / Muffler / Unit manual
3. Alternator / connection elbow / unit product quality certificate
4. Steel structure chassis / Battery and cable / Control screen
5. MCCB air protection switch / Damping pad / Engine original quality file
6. Generator original quality documents
