Xieli Machinery Grinding carbon steel pipe aluminum pipe stainless steel pipe precision new centerless grinding machine

WX-M2-60 Centerless Grinding machine

Longitudinal feed grinding

Grinding workpiece diameter

0.8–60mm

Grinding length  (max)

1000mm

Horizontal feed grinding

Grinding workpiece diameter

2–60mm

Grinding length  (max)

125mm

Grinding wheel specification

P350*125*127

Guide wheel specification

P250*125*75

Grinding wheel rotating speed

2000r/min

Guide wheel rotating speed

stepless5-240r/min

Guide wheel rotary angle

In the vertical plane

-2° -5°

In the horizontal plane

-10°-10°

Standard test bar

   grinding accuracy

(ø 20 × 75 )

Roundness

2 μ m

Cylindricity

3 μ m

Roughness

Ra0.2 μ m

Grinding feed

Feed amount of each grid of dial  0.002mm

Cooling pump flow

25L/min

Equipment power     5KW

Grinding wheel motor

4.0kw

Guide wheel motor

0.75kw

Cooling pump motor

0.09kw

Machine tool lead-in power supply

Three phase four wire  380V 50Hz

Machine dimension

1300*960*1300mm

Machine tool weight approx

1000kg
