12~400 deg.C Biphenyl Diphenyl Ether CAS No 8004 13 5 Heat Transfer Fluids Oil

Product Overview

Description



12~400deg.C Biphenyl Diphenyl Ether CAS No 8004-13-5 Heat Transfer Fluids Oil



Product name:Biphenyl & Diphenyl Ether

Model name: AT-400

Affiliated category: Heat Transfer fluid

Working temperature:12~400deg.C



Details:

The biphenyl diphenyl ether mixture heat transfer oil is a thermally stable high gas/liquid dual-purpose high temperature synthetic organic heat carrier composed of a eutectic mixture of 26.5% biphenyl and 73.5% diphenyl ether. It can be used as a liquid phase heat transfer oil, or it can be used as a gas phase heat transfer oil in the temperature range of 257℃ to 400℃by its evaporation - condensation characteristics, and is widely used in the CSP solar thermal power generation industry and the chemical fiber chemical industry.

Excellent thermal stability, a synthetic heat transfer oil with excellent thermal stability and low viscosity characteristics, which provides effective, reliable and consistent performance over a wide temperature range of 12 ° C to 400 ° C; Low vapor pressure, biphenyl-diphenyl ether mixture heat transfer oil at its high temperature vapor pressure is quite low, the saturated vapor pressure is slightly greater than 1Mpa at 400 °C.

Color:clear to light yellow



Main Technical Data

Executive standard: GB 23971-2009
Crystallization point	11.8~12.3℃
Boiling range	253-258℃
Flash point(open)	≥140℃
Autoignition Temperature	>618℃
Water content	≤0.03%
Kinematic viscosity 40 ℃ , mm2/s	2.2~2.8
Specific density 20℃	1.060-1.065g/cm3
Average molecular weight	166
Sulphur content %	≤2ppm
Chloride content %	≤5ppm
