Factory conveyor wire hook steel conveyor belt fastener for conveyor
- Category: >>>
- Supplier: Lixian Huadu Rubber Belts Co. Ltd.
Share on (1600699862993):
Product Overview
Description
What is the details of our product?
Size | Length of Plate/mm | Width of plate/mm | Distance of holes/mm | Bolt Sizes/mm | Apply Belt thickness/mm | Blet Strength | Pulley size/mm |
140E | 57 | 21 | 36 | 6X42 | 5-11 | 400N/mm | 400-600 |
190E | 67 | 21 | 48 | 6X42 | 8-14 | 500N/mm | 610-760 |
1.5" | 63 | 27 | 41 | 8X45 | 11-17 | 500N/mm | 610-760 |
2" | 83 | 29 | 54 | 8X45 | 14-21 | 750N/mm | 640-760 |
2.5" | 102 | 38 | 64 | 10X59 | 19-25 | 800N/mm | 1070 |
3.0" | 114 | 38 | 77 | 10X59 | >24 | 2000N/mm | 1200 |
Model | Belt Thinckness Range | Strength | Minimum Pulley Diameter | Diamet special tool speces | ||||||
Inch | mm | Pounds/Square feet | KN/m | inch | mm | |||||
140E | 3/16---7/16 | 5-11 | 225 | 40 | 14 | 360 | A | |||
190E | 5/16---9/16 | 8-14 | 375 | 65 | 18 | 460 | A | |||
1.5" | 7/16---11/16 | 11-17 | 300 | 50 | 18 | 460 | B | |||
2" | 9/16---13/16 | 14-21 | 440 | 75 | 18 | 760 | B | |||
2.5" | 3/4----1 | 19-25 | 450 | 75 | 30 | 1070 | C | |||
3.0" | 1 or more | 24 and more | 560 | 100 | 42 | 1200 | C | |||
What is the package of our product?
Conveyor belt Fastner package details:
1.bulk package
2.Carton Package
So many suppliers, why choose us?
Company Profile
Huadu specializes in the production of " rubber conveyor belt series products, with an annual output of various
types of rubber conveyor belt more than 25000000 square meters.The main varieties of conveyor belt are common type
(nylon,polyester, steel cord), oil resistance, chemical resistance, heat resistance, cold resistance, fire-resistant, anti-tear,
chevron conveyor belt, etc., is widely used in steel, electric power, port, metallurgy, mining, cement and other
industries.Theproducts are sold well in more than 20 provinces, cities and regions in China, and exported to more than 50
countries and regions such as Europe, America, Middle East, southeast Asia, Africa and Australia, winning good international and
domestic reputation.
types of rubber conveyor belt more than 25000000 square meters.The main varieties of conveyor belt are common type
(nylon,polyester, steel cord), oil resistance, chemical resistance, heat resistance, cold resistance, fire-resistant, anti-tear,
chevron conveyor belt, etc., is widely used in steel, electric power, port, metallurgy, mining, cement and other
industries.Theproducts are sold well in more than 20 provinces, cities and regions in China, and exported to more than 50
countries and regions such as Europe, America, Middle East, southeast Asia, Africa and Australia, winning good international and
domestic reputation.
