Promotional Gas Filling 175L 195L Liquid Nitrogen Cylinders for Sale
- Category: >>>
- Supplier: Shandong,Yongan,Heli,Special,Equipment,Co.,Ltd.
Share on:
Product Overview
Description
PRODUCT SPECIFICATIONS
Product name | Low Temperature Insulated Gas Cylinder | ||||||||||||
Product Specifications | DPL450- 175/195/210 -1.4 | DPL450- 175/195/210 -2.01 | DPL450- 175/195/210 -2.3 | DPL450- 175/195/210 -2.88 | DPL700- 410/450/500 -3.17 | DPL900-1000-2.45 | |||||||
Nominal volume/effective volume (L) | (175/166) (195/185) (210/199) | (410/377) (450/414) (500/460) | (1000/920) | ||||||||||
Working medium | liquid oxygen, liquid nitrogen, liquid argon, carbon dioxide, helium oxide | ||||||||||||
Working pressure (MPa) | 1.4 | 2.01 | 2.3 | 2.88 | 3.17 | 2.45 | |||||||
Minimum operating temperature (℃) | -196 | ||||||||||||
Air tightness test pressure (MPa) | 1.4 | 2.01 | 2.3 | 2.88 | 3.17 | 2.45 | |||||||
Opening pressure setting of primary safety valve MPa(≤) | 1.59 | 2.41 | 2.76 | 3.45 | 3.45 | 2.76 | |||||||
Bursting pressure setting of liner bursting disc MPa(≤) | 2.6 | 3.6 | 3.6 | 5.17 | 5.17 | 3.6 | |||||||
Static evaporation %rate/d (liquid nitrogen) | 1.9 | 1.9 | 1.9 | 1.9 | 1.7 | 1.9 | |||||||
Empty weight of container (kg) | 110/116/119 | 125/133/140 | 132/140/148 | 143/156/162 | 326/347/370 | 817 | |||||||
Overall dimensions (mm) | Φ516X 1500/1610/1700 | Φ766X1535/1640/1765 | Φ964X2040 | ||||||||||
Maximum filling capacity (kg) | volume | 175/195/210 | 410/450/500 | 1000 | |||||||||
liquid oxygen | 189/210/226 | 429/472/524 | 1048 | ||||||||||
liquid nitrogen | 134/149/161 | 305/335/372 | 745 | ||||||||||
liquid argon | 234/260/280 | 527/579/644 | 1288 | ||||||||||
liquid carbon dioxide | / | 182/203/218 | 392/430/478 | 956 | |||||||||
liquid Nitrous oxide | / | 212/236/254 | 482/529/588 | 1177 | |||||||||
•Features:
1.Used for the storage and transport of liquid argon/liquid oxyge/liquid nitrogen/liquid carbondioxide/LNG etc.
2.Equip the vaporizer inside,provide 10m3/h continuous gas supply
3.Adopt the international standard connectors,all valves are imported brands.Also can customize according to the customers.
4 Design of dasmping ring make sure the transportation safely.
5 Are widely used in the industries of Chemical /machinery /shipbuilding/ hospital /electronic /medical /material /energy /research.
Details Images
Company Profile
FAQ
1. who are we?
We are based in Shandong, China, start from 2013,sell to Domestic Market(40.00%),Southeast Asia(13.00%),South
America(10.00%),South Asia(8.00%),North America(6.00%),Africa(5.00%),Mid East(5.00%),Eastern Asia(3.00%),Eastern
Europe(2.00%),Western Europe(2.00%),Central America(2.00%),Northern Europe(2.00%),Southern Europe(2.00%). There are total about 301-500 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;
3.what can you buy from us?
Seamless Stel Cylinder,Oxygen Bottle,Liquefied Gas Cylinder,Acetylene Cylinder,Welded Gas Cylinder,Gas Cylinders
We are based in Shandong, China, start from 2013,sell to Domestic Market(40.00%),Southeast Asia(13.00%),South
America(10.00%),South Asia(8.00%),North America(6.00%),Africa(5.00%),Mid East(5.00%),Eastern Asia(3.00%),Eastern
Europe(2.00%),Western Europe(2.00%),Central America(2.00%),Northern Europe(2.00%),Southern Europe(2.00%). There are total about 301-500 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;
3.what can you buy from us?
Seamless Stel Cylinder,Oxygen Bottle,Liquefied Gas Cylinder,Acetylene Cylinder,Welded Gas Cylinder,Gas Cylinders
