High Quality Customized one stop service pcb board factory bluetooth usb mp3 player circuit board pcb
- Category: Double-sided PCB >>>
- Supplier: Qimao Electronics (Dingnan) Co. Ltd.
Share on (1600702017189):
Product Overview
Description
Products Description
ITEMS | Parameter | ||||||||||||
Double side & Multi-layer | |||||||||||||
Number of Layers | 1-20 layers | ||||||||||||
Board Materials | FR4,CME3,CME1,5G | ||||||||||||
PCB Size (Min- Max) | 50x80mm to 1000mm×600mm ( 39.37"x23.6") | ||||||||||||
innerlayer line width/space(min) | 4mil/4mil(100um/100um) | ||||||||||||
Finish Plating /Surface Finishes | HASL ,OSP,ENIG,HASL,gold finger,Au Panel,OSP,ENIG | ||||||||||||
innerlayer pad (min) | 5mil(0.13mm) | ||||||||||||
Core thickness (min) | 8mli(0.2mm) | ||||||||||||
Finisher Copper Inner Layers | 1/2oz(17um)a- | ||||||||||||
Finished Copper Outer Layers | 1/2oz(17um) | ||||||||||||
Final PCB Thickness (tolerance %) | 0.5-4.0mm | ||||||||||||
Final PCB Thickness (tolerance %) | Thickness<1.0mm | ||||||||||||
1.0mm≤Thickness<2.0mm | |||||||||||||
Thickness≥2.0mm | |||||||||||||
inner layer process | Brown Oxide | ||||||||||||
Minimum Conductor Space | ±3mil(±76um) | ||||||||||||
Minimum Drill Hole Size | 0.25mm | ||||||||||||
min diameter of finished hole | 0.2mm | ||||||||||||
Hole position accuracy | ±2mil(±50um) | ||||||||||||
Drilled slot tolerance | ±3mil(±75um) | ||||||||||||
PTH tolerance | ±2mil(±50um) | ||||||||||||
NPTH tolerance | ±1mil(±25um) | ||||||||||||
maxA.R.Of PTH | 8:01 | ||||||||||||
PTH hole copper thickness | 0.4-2mil(10-50um) | ||||||||||||
image to image tolerance | ±3mil(0.075mm) | ||||||||||||
outer layer line width/space(min) | 3mil/3mil(75um/75um | ||||||||||||
Solder Mask Thickness | line end 0.4-1.2mil(10-30um) | ||||||||||||
line Corner ≥0.2mil(5um) | |||||||||||||
on Substrate | ≤Finished Cu | ||||||||||||
thickness+1.2mm≤Finished Cu | |||||||||||||
thickness+30um)≤+1.2mil≤+30um) | |||||||||||||
min solder mask dam | 4.0mil(100um) | ||||||||||||
impedance control and tolerance | 50Ω±10% | ||||||||||||
warp and twist | ≤0.5% | ||||||||||||
Delivery time | 1-2 layers 10-12day | ||||||||||||
4-20 layers 12-20days | |||||||||||||
Package | General export packaging | ||||||||||||
