New type of waste tire pyrolysis plant to oil high output small plastic pyrolysis machine with install

Model:LJ-10                                                                     Raw material:Waste tire, waste plastic, waste rubber

Structure:Horizontal                                                         24hours processing capacity:10-12tons raw materials

24hours oil output:4-6tons fuel oil                                 Work pressure:Atmospheric

Host speed:0.4r\\min                                                        Power:15.5KW

Cooling:Water cooling                                                      Lose water(T\\H):8

Transport:External gear drive                                          Heating method:Directly

Installation:Foundation                                                    Noise dB(A):≤85

Reactor size length*wideth:2600x6600                         Working form:batch

Weight of Reactor(T):30                                                    Manufacuring time:20days

This kind of machine does not have to get rid of silt, moisture content, iron wire impurity and so on from the scrap plastic, directly loads in the rotary system high temperature atmospheric pressure split processor, catalyses, heats up, distils oil steam, the oil gas through the condenser, the liquefied part condense into the oil mixture, and the unliquefied part holds through  the fuel gas system into the processor bottom to burn.After the mixture oil condense, put into fractionation processor to heat though catalytic reforming process, and get the oil steam. Then the oil steam through the condenser to be basic fuel, and add various additives to become qualified fuel.
