Winston IP65 2 IN 2 OUT 2 Strings 15A 500V DC Solar PV Array Combiner Box
- Category: Solar Applications >>>
- Supplier: Yueqing,Winston,Electric,Co.,Ltd.
Share on:
Product Overview
Description
Products Description
(1) meet the requirements of outdoor installation, protection class IP65, with anti-UV, anti-acid, anti-alkali, moisture, mildew,rodent control and other functions;
(2) access 16-way PV array, each with 15A, 1000Vdc fuse (replaceable other grades);
(3) Equipped with special high-voltage lightning protection device, lightning protection function with cathode and anode ;
(4) Positive, negative string into the fuse;
(5) Use quadruple PV dedicated circuit breaker with positive and negative in series;
Specifications
Name | DB-PV2 | ||
Electric parameter | |||
System maximum dc voltage | 550 | 1000 | |
Maximum input current for each string | 15A | ||
Maximum input strings | 2 | ||
Maximum output switch current | 20A/32A | ||
Number of inverter MPPT | 1 | ||
Number of Output strings | 1 | ||
Lightning protection | |||
Category of test | II grade protection | ||
Nominal discharge current | 20kA | ||
Maximum discharge current | 40kA | ||
Voltage protection level | 2.8kV | 3.8kV | |
Maximum continuous operating voltage Uc | 630V | 1050V | |
Poles | 2P | 3P | |
Structure characteristic | Plug-push module | ||
System | |||
Protection grade | IP65 | ||
Output switch | DC isolation switch(standard)/DC circuit breaker(optional) | ||
SMC4 Waterproof Connectors | Standard | ||
PV dc fuse | Standard | ||
PV surge protector | Standard | ||
Monitoring module | Optional | ||
Preventing diode | Optional | ||
Box material | PVC | ||
Installation method | Wall mounting type | ||
Operating Temperature | 25°C~+55°C | ||
Elevation of temperature | 2km | ||
Permissible relative humidity | 0-95%,no condensation | ||
Mechanical parameter | |||
Width*High*Depth | 300*260*140 | ||
