Tear resistant ep500 600 800 4ply conveyor belt industry rubber mining conveyor belting
- Category: Rubber Belts >>>
- Supplier: Ningbo,Kilomega,International,Trade,Co.,Ltd.
Share on:
Product Overview
Description
Products Description
kilomega conveyor belt are designed to the highest standards ,to transport all types of bulk material,including mining, stone andearth handling , building industries,recycling, steel processing , wood, paper and pulp.
Features of conveyor belt
—— High strength
—— High resistant to abrasion
——Low elongation
—— Resistant to impact
——Suitable for long distance,large loading capacity and high speed transportation
——Low elongation
—— Resistant to impact
——Suitable for long distance,large loading capacity and high speed transportation
Structure of conveyor belt
——Adhesion Rubber
——Top Cover Rubber
——NN, EP Fabric Rubber
——Bottom Cover Rubber
Products range
——Wear resistant conveyor belt
——Heat resistant conveyor belt
——Cold resistant conveyor belt
——Oil resistant conveyor belt
——Flame retardant conveyor belt
——Acid-alkaline resistant conveyor belt
——Steel cord conveyor belt
——Steel cord conveyor belt
——Chevron conveyor belt
——Pipe conveyor belt
——Endless conveyor belt
—— Sidewall conveyor belt
—— Sidewall conveyor belt
Specification and parameter
Fabric specs | Ply thinkness(mm/p) | Strength series | Cover thickness | Width(mm) | ||||||||||
2ply | 3ply | 4ply | 5ply | 6ply | Top | Bottom | ||||||||
NN-100 | 0.75 | 200 | 300 | 400 | 500 | 600 | 1.5-8 | 400-2500 | ||||||
NN-150 | 0.80 | 300 | 450 | 600 | 750 | 900 | ||||||||
NN-200 | 0.90 | 400 | 600 | 800 | 1000 | 1200 | 500-2500 | |||||||
NN-250 | 1.15 | 500 | 750 | 1000 | 1250 | 1500 | ||||||||
NN-300 | 1.25 | -- | 900 | 1200 | 1500 | 1800 | 100-2500 | |||||||
NN-400 | 1.45 | -- | -- | 1600 | 2000 | 2400 | ||||||||
NN-500 | 1.55 | -- | -- | 2000 | 2500 | 3000 | ||||||||
Fabric specs | Ply thinkness(mm/p) | Strength series | Cover thickness | Width(mm) | ||||||||||
2ply | 3ply | 4ply | 5ply | 6ply | Top | Bottom | ||||||||
EP-80 | 0.6 | 160 | 240 | 320 | 400 | 480 | 2.0-8 | 0-4..5 | 400-2500 | |||||
EP-100 | 0.75 | 200 | 300 | 400 | 500 | 600 | ||||||||
EP-150 | 1.00 | 300 | 450 | 500 | 750 | 900 | 500-2500 | |||||||
EP-200 | 1.10 | 400 | 600 | 750 | 1000 | 1200 | ||||||||
EP-250 | 1.25 | 500 | 750 | 1000 | 1250 | 1500 | ||||||||
EP-300 | 1.35 | 600 | 900 | 1200 | 1500 | 1800 | 800-3500 | |||||||
EP-350 | 1.45 | -- | 1050 | 1400 | 1750 | 2100 | ||||||||
EP-400 | 1.55 | -- | -- | 1600 | 2000 | 2400 | 100-2500 | |||||||
EP-500 | 1.70 | -- | -- | 2000 | 2500 | 3000 | ||||||||
You May Also Like
Quality control
We have an inspection team to inspect the surface and dimension of each conveyor belt. If any problem on belt surface, we will repair at once in our factory.
Width inspection
Length inspection
Surface inspection
We have a lab to test all raw materials and rubber compound.For each roll of conveyor belt,the lab will test the following features, and issue Quality Test Report.
Thickness inspection
Tensile strength inspection
Hardness inspection
Adhesive inspection
Whole belt strength inspection
Abrasion inspection
Production and application
The selection of raw materials for eachp roduct is strictly controlled, and each process is kept improving. just to deliver eachproduct to customers.
Packing and shipping
Company profile
Ningbo Kilomega International Trade Co.,Ltd is specialized in exporting Mining, Crusher Plants and rent contract productionline.We export full range of mine crusher machinery and spare parts, including crushers, belt conveyor, gear boxes,electronicmotors,screen mesh, conveyor belts and relative accessories. We practice an opening-up strategies of mutual benefit and win forall, willing to work with you to create a better future.
FAQ
Q1. Are you a manufactuer?
Yes, we mainly produce Rubber conveyor belts and Rubber v belts over 20 years.
Yes, we mainly produce Rubber conveyor belts and Rubber v belts over 20 years.
In order to ensure the quality of products, after the production of products, we have to carry out strict inspection and record.So you can buy with confidence.
Q3.what can you buy from us?
conveyor belt,steel roller,screen mesh,crusher,crusher parts
Q4. why should you buy from us not from other suppliers?
We have full range of mining equipments and spare parts. We have more than 10 years experience for exporting to 20+ countries.
Q4. why should you buy from us not from other suppliers?
We have full range of mining equipments and spare parts. We have more than 10 years experience for exporting to 20+ countries.
