Precision grade than mechanical pressure switch Cost effective Precision grade Stainless steel structure
- Category: >>>
- Supplier: Nanjing Hangjia Electronic Technology Co. Ltd.
Share on (1600710975722):
Product Overview
Description
Product Description
Features:
* Cost-effective
* Stainless steel structure, corrosion resistant performance is good
* Small volume, light weight
* Precision grade than mechanical pressure switch
* Before they leave the switch quantity can be set arbitrary between zero to the full
* Normally open or normally closed switch types are optional
* Various optional interface pressure and electrical interface
Specification
Pressure Range | -100kPa～60MPa |
Accuracy | ±0.5%FS |
overload capacity | 150% |
Pressure Type | Gauge pressure or Absolute pressure |
Stability | ≤0.2%FS/year |
Supply Voltage | 18～26VDC |
Switch Type | 1 way relay, can be set open or close |
Switch Life | >1 million times |
Respond Time | ≤30ms |
Medium Temperature | -40～120℃ |
Storage Temperature | -40～120℃ |
Protection Grade | IP65 |
Shock Resistant | 20g/20～5000Hz |
