Excellent Mechanical Properties and Chemical Resistance vinyl ester resin for yacht
- Category: >>>
- Supplier: Jiangyin Thousands Chemicals Co. Ltd.
Share on (1600712156502):
Product Overview
Description
Atlac ® 430 epoxy bisphenol A vinyl ester resin
CHEMICAL/PHYSICAL NATURE
Atlac® 430 is an epoxy bisphenol A vinyl ester, dissolved in styrene.
MAJOR APPLICATIONS
Atlac® 430 can be used in all fabrication methods, but is especially adapted to meet the requirements of filament winding, centrifugal casting, hand lay-up and spray-up applications.
Atlac® 430 provides resistance to a wide range of acids, alkali, and bleaches for the use in corrosive environments in the chemical processing industry. The favorable combination of thermal resistance and elongation makes this resin suitable for applications exposed to intermittent temperatures.
APPROVALS
Cured non-reinforced Atlac® 430 conforms to type 1310 according to DIN 16946/2 and is classified group 5 according to DIN 18820/1. According to EN13121/2 Atlac® 430 is classified group 7A.
PROCESSING
Atlac® 430 normally exhibits tack-free cure. However, the surface may not be cured completely. To ensure tack-free
curing of surfaces exposed to air, suitable additives (e.g. paraffin solution) should be added. The final state of cure may further be optimized by post-curing at elevated temperatures (e.g. 80 or 100 °C) for several hours. Post-curing is especially recommended if parts made from Atlac® 430 are intended for contact with chemicals. Atlac® 430 may be cured using MEK-Peroxide with a low content of hydrogen peroxide (e.g. Butanox LPT-IN, Curox M-102, with CHP and cumene hydroperoxide (e.g. Trigonox 239, Luperox Cu 50 VE).
curing of surfaces exposed to air, suitable additives (e.g. paraffin solution) should be added. The final state of cure may further be optimized by post-curing at elevated temperatures (e.g. 80 or 100 °C) for several hours. Post-curing is especially recommended if parts made from Atlac® 430 are intended for contact with chemicals. Atlac® 430 may be cured using MEK-Peroxide with a low content of hydrogen peroxide (e.g. Butanox LPT-IN, Curox M-102, with CHP and cumene hydroperoxide (e.g. Trigonox 239, Luperox Cu 50 VE).
GUIDELINES BEFORE USE
The resin should be conditioned at a well-defined, application dependent temperature (usually 15 °C minimum for a MEKP/Co cure).
STORAGE GUIDELINES
The resin should be stored indoors in the original, unopened and undamaged packaging, in a dry place at temperatures between 5°C and 30°C and the properties might change during storage. Shelf life is reduced at higher temperatures and the properties of the resin might change during storage. The shelf life of styrene containing unsaturated polyesters will be significantly reduced when exposed to light. Store in dark and in 100%light tight containers only.
MATERIAL SAFETY
A Material Safety Data Sheet of this product is available on request. TEST METHODS Test methods
(TM) referred to in the table(s) are available on request.
(TM) referred to in the table(s) are available on request.
Recommend Products
Standard epoxy vinyl ester resin for vaccum infusion process
Atlac® 430 LV GT 250 can be used for glass fiber with excellent chemical resistance vvreinforce components to obtain better
mechanical properties, and have good compatibility with carbon fiber and aramid. Good combination, can be used in such as: boats,
auto parts, storage tanks, containers, corrosion resistance corrosion protection, water conservancy projects, repair of sewer
pipes, etc. Atlac® 430 LV GT 250 has a very low viscosity, suitable for vacuum introduction, RTM and other processes Art; and
obtained the China Classification Society CCS certification and Lloyd's Register of Shipping LR certification.
mechanical properties, and have good compatibility with carbon fiber and aramid. Good combination, can be used in such as: boats,
auto parts, storage tanks, containers, corrosion resistance corrosion protection, water conservancy projects, repair of sewer
pipes, etc. Atlac® 430 LV GT 250 has a very low viscosity, suitable for vacuum introduction, RTM and other processes Art; and
obtained the China Classification Society CCS certification and Lloyd's Register of Shipping LR certification.
Brominated VE resin for
fire retardant and anti-
corrosion environments
fire retardant and anti-
corrosion environments
Atlac ® 430YT resin is resistant to corrosion by various acids, alkalis, bleaches and organic compounds, especially suitable for chimney and chimney lining in FRP pipe system. It is also suitable for equipment, building boards and floor materials that need to be equipped with no-fire conditions to deal with air and hot gas mixtures. The resin is designed for ease of fabrication using hand lay-up, spray-up, filament winding, RTM and pultrusion techniques. Additives such as antimony trioxide can be added to further improve the flame retardant performance, on condition
that not affecting the processing performance.
that not affecting the processing performance.
Model | Type | Description | Application |
Atlac ® 590UHT | Novolac epoxy vinyl ester resin for corrosive environments at ultra high temperature | Components based on Atlac ® 590UHT feature superior retention of mechanical properties at high temperature, and superior corrosion to oxidizing chemicals and solvents etc. | Atlac ® 590UHT resin is the preferred choice for applications with high operating/design temperatures. This resin is designed for ease of fabrication using hand lay-up, spray-up, filament winding, compression molding and resin transfer molding techniques. Atlac ® 590UHT resin has been applied in chemical storage tanks, pipes, flue gas desulfurization systems (FGD), stacks, scrubbers, ducts. Atlac ® 590UHT resin has excellent resistance to organic solvents due to itself high crosslinking density. |
Atlac ® 590Z | Novolac epoxy vinyl ester resin for corrosive environments | Atlac ® 590Z provides excellent thermal and chemical resistance against solvents, acids and oxidizing media like chlorine. The resin offers high retention of strength at elevated temperatures. | Atlac ® 590Z is a styrene solution of phenolic modified vinyl resin with moderate reactivity and viscosity. Atlac ® 590Z offers excellent high temperature stability and corrosion resistance to organic solvents, acids and oxidizing media such as chlorine, as well as high temperature strength retention. Atlac ® 590Z is suitable for most production processes, especially for filament winding, centrifugal casting, hand lay-up and spray-up. It can also be used to prepare glass flake coating and cement paste. |
Atlac ® 430YT | Brominated VE resin for fire retardant and anti- corrosion environments | Atlac ® 430YT feature good corrosion resistance, mechanical properties, and excellent flame retardant properties. | Atlac ® 430YT resin is resistant to corrosion by various acids, alkalis, bleaches and organic compounds, especially suitable for chimney and chimney lining in FRP pipe system. It is also suitable for equipment, building boards and floor materials that need to be equipped with no-fire conditions to deal with air and hot gas mixtures. The resin is designed for ease of fabrication using hand lay-up, spray-up, filament winding, RTM and pultrusion techniques. Additives such as antimony trioxide can be added to further improve the flame retardant performance, on condition that not affecting the processing performance. |
ATLAC® 430 | Standard epoxy bisphenol A vinyl ester resin | Atlac ® 430 can be used in all fabrication methods, but is especially adapted to meet the requirements of filament winding, centrifugal casting, hand lay-up and spray-up applications. | Atlac ® 430 provides resistance to a wide range of acids, alkali, and bleaches for the use in corrosive environments in the chemical processing industry. The favorable combination of thermal resistance and elongation makes this resin suitable for applications exposed to intermittent temperatures. |
